Vertex Standard VXR-9000 Service Manual

J-6
PANEL Unit
Parts List
VXR-9000 UHF Service Manual
C 4053 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a2
D 4001 LED GL8PR21 G2090395 1-79 A A2
D 4001 LED SLB-25VR G2090806 80- A A2
D 4002 DIODE MC2850-T111-1 G2070704 1- A A2
D 4003 LED GL8KG21 G2090625 1-87 A A2
D 4003 LED SLB-25MG G2090807 88- A A2
D 4004 DIODE BAS316 G2070716 1- B c2
D 4005 LED GL8EG22 G2090561 1-68 A E2
D 4005 LED MPG5353K G2090809 69- A E2
D 4006 DIODE MC2850-T111-1 G2070704 1- B b2
D 4008 DIODE BAS316 G2070716 1- B b2
D 4009 LED GL8PR22 G2090431 1-68 A D2
D 4009 LED BR5353K G2090808 69- A D2
D 4010 LED TLOU1008(T04) G2070796 1-127 A B1
D 4010 LED SML-512DWT86 G2071116 128- A B1
D 4011 DIODE MC2850-T111-1 G2070704 1- B d2
D 4012 LED TLOU1008(T04) G2070796 1-127 A C1
D 4012 LED SML-512DWT86 G2071116 128- A C1
D 4013 DIODE MC2850-T111-1 G2070704 1- B b2
D 4014 LED TLOU1008(T04) G2070796 1-127 A B2
D 4014 LED SML-512DWT86 G2071116 128- A B2
D 4015 DIODE MC2850-T111-1 G2070704 1- B d2
D 4016 DIODE MC2850-T111-1 G2070704 1- B d1
D 4017 LED TLOU1008(T04) G2070796 1-127 A C2
D 4017 LED SML-512DWT86 G2071116 128- A C2
D 4018 LED TLOU1008(T04) G2070796 1-127 A B3
D 4018 LED SML-512DWT86 G2071116 128- A B3
D 4019 DIODE MC2850-T111-1 G2070704 1- B d2
D 4020 LED TLOU1008(T04) G2070796 1-127 A C3
D 4020 LED SML-512DWT86 G2071116 128- A C3
D 4021 DIODE MA729-(TX) G2070320 1-104 B d1
D 4021 DIODE DB2J31300L G2071338 105- B d1
D 4100 LED LB-602DA2 G2090779 1-
J 4001 CONNECTOR IL-FHR-F30S-HF-E3000 P1091027 1-3 B c3
J 4001 CONNECTOR 9637S-30-Y905 P1091169 4- B c3
J 4002 CONNECTOR R41-2509H P1090714 1- A A4
JP4001 WIRE ASSY BLK 70 (5)/(5) T54007022 1-
JP4002 WIRE ASSY BLK 85 (5)/(5) T54008522 1-
Q 4001 IC NJM2902V-TE1 G1091679 1- B e3
Q 4002 TRANSISTOR DTC323TK T146 G3070042 1- B e3
Q 4003 IC BU4094BCFV-E2 G1093527 1- B c2
Q 4004 TRANSISTOR DTC144EE TL G3070075 1- B e3
Q 4005 TRANSISTOR XN1213-(TX) G3070194 1-115 B e3
Q 4005 TRANSISTOR DMC261030L G3070445 116- B e3
Q 4006 TRANSISTOR RT1P441U-T11-1 G3070248 1- A A3
Q 4007 TRANSISTOR XN1213-(TX) G3070194 1-115 B b2
Q 4007 TRANSISTOR DMC261030L G3070445 116- B b2
Q 4008 IC BU4066BCFV-E2 G1093537 1- B e1
Q 4009 TRANSISTOR XN1213-(TX) G3070194 1-115 B d1
Q 4009 TRANSISTOR DMC261030L G3070445 116- B d1
Q 4010 TRANSISTOR XN1213-(TX) G3070194 1-115 B d2
Q 4010 TRANSISTOR DMC261030L G3070445 116- B d2
Q 4011 IC BU4094BCFV-E2 G1093527 1- B b3
Q 4012 TRANSISTOR DTC144EE TL G3070075 1- B d2
Q 4013 TRANSISTOR XN1213-(TX) G3070194 1- B d3
Q 4014 IC BU4094BCFV-E2 G1093527 1- B a2
Q 4015 TRANSISTOR XN1213-(TX) G3070194 1-115 B a2
Q 4015 TRANSISTOR DMC261030L G3070445 116- B a2
Q 4016 TRANSISTOR XN1213-(TX) G3070194 1-115 B c1
Q 4016 TRANSISTOR DMC261030L G3070445 116- B c1
Q 4017 TRANSISTOR XN1213-(TX) G3070194 1-115 B c2
Q 4017 TRANSISTOR DMC261030L G3070445 116- B c2
Q 4018 TRANSISTOR XN1213-(TX) G3070194 1-115 B a1
Q 4018 TRANSISTOR DMC261030L G3070445 116- B a1
Q 4019 TRANSISTOR XN1213-(TX) G3070194 1-115 B a1
Q 4019 TRANSISTOR DMC261030L G3070445 116- B a1
Q 4020 TRANSISTOR XN1213-(TX) G3070194 1-115 B a2
Q 4020 TRANSISTOR DMC261030L G3070445 116- B a2
Q 4021 TRANSISTOR XN1213-(TX) G3070194 1-115 B c1
Q 4021 TRANSISTOR DMC261030L G3070445 116- B c1
Q 4022 TRANSISTOR XN1213-(TX) G3070194 1-115 B c2
Q 4022 TRANSISTOR DMC261030L G3070445 116- B c2
QS4001 IC SOCKET 110-99-624 P3090110 1-16 A E1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
