Vertex Standard VXR-9000 Service Manual

O-7
100W PA Unit (Option: Version D)
Parts List
VXR-9000 UHF Service Manual
Q 6017 TRANSISTOR DTC144EE TL G3070075 1- A A2
R 6001 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A4
R 6002 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A B2
R 6003 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A B2
R 6004 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A4
R 6005 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A5
R 6006 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A A5
R 6007 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 6008 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B4
R 6009 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6010 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A5
R 6011 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A I2
R 6012 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C3
R 6013 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A I2
R 6014 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 6015 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A H2
R 6016 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 6017 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A B5
R 6018 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A B5
R 6019 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 6020 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B5
R 6021 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B3
R 6022 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A I2
R 6023 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A H2
R 6024 CHIP RES. 12 1/10W 5% RMC1/10T 120J J24205120 1- A A5
R 6025 CHIP RES. 12 1/10W 5% RMC1/10T 120J J24205120 1- A B5
R 6026 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A H2
R 6027 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6029 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A B5
R 6030 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A B6
R 6031 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A B6
R 6032 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B5
R 6033 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A3
R 6035 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B3
R 6036 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101 1- A C5
R 6037 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B3
R 6038 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A A3
R 6039 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 6040 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6041 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A2
R 6042 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B3
R 6043 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B4
R 6044 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A F5
R 6045 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A F8
R 6046 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A2
R 6047 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A F5
R 6048 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6049 METAL FILM RES. 100 150W 1% RFRF150C100F J22529001 1- A H5
R 6050 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A F7
R 6051 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A2
R 6052 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F4
R 6053 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F7
R 6054 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A F4
R 6055 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A F7
R 6056 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A2
R 6057 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A F4
R 6058 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A F7
R 6059 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A A2
R 6060 CHIP RES. 150 1/10W 5% RMC1/10T 151J J24205151 1- A J6
R 6061 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A2
R 6062 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A2
R 6063 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A A3
R 6064 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J5
R 6065 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A J5
R 6066 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A A3
R 6067 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A J5
R 6068 CHIP RES. 150 1/10W 5% RMC1/10T 151J J24205151 1- A K5
R 6069 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A K6
R 6070 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A A3
R 6071 CHIP RES. 680 1/16W 5% RMC1/16 681JATP J24185681 1- A K6
R 6072 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A K6
R 6073 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6074 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A A3
