Vertex Standard VXR-9000 Service Manual

L-7
PA-2 Unit (Lot. 21~)
Parts List
VXR-9000 UHF Service Manual
R 8022 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101 1- A E2
R 8023 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D3
R 8024 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D3
R 8025 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B4
R 8026 CHIP RES. 150 1/10W 5% RMC1/10T 151J J24205151 1- A D3
R 8027 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A D3
R 8028 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E3
R 8029 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- A E3
R 8030 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D2
R 8031 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D2
R 8032 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A D3
R 8033 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E2
R 8034 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D3
R 8035 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A D3
R 8036 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F4
R 8037 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A F4
R 8038 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A F4
R 8039 CHIP RES. 22 1/10W 5% RMC1/10T 220J J24205220 1- A F4
R 8040 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A G1
R 8041 CEMENT RES. 5.6 5W 10% ERF-5AK5R6 J30376569 1-61 A E5
R 8041 CEMENT RES. 5.6 5W 5% BWR5C5R6J J30375569 62- A E5
R 8043 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D3
R 8044 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A A4
R 8045 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A A3
R 8046 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 8047 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 8048 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 8049 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
RL8001 RELAY DC12V ACP131 DC12V M1190152 1- A F5
S 8001 SLIDE SWITCH SSSS912N-2A-OR N6090094 1- A F4
TH8001 THERMISTOR 157-203-55009TP G9090045 1- A C4
SHIELD PLATE PA R0124501 1-
BINDING HEAD SCREW M3X10NI U20310002 1-
BINDING HEAD SCREW M3X10NI U20310002 1-
TERMINAL B4 AG M3 Q6000114 1-
TERMINAL B4 AG M3 Q6000114 1-
GASKET L=50 RA0650800 1-
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
