L-6
PA-2 Unit (Lot. 21~)
Parts List
VXR-9000 UHF Service Manual
D 8003 DIODE RN739F T106 G2070626 1- A A3
D 8004 DIODE HZM4.7NB2 TR-E G2070782 1-102 A B2
D 8004 DIODE HZM5.6NB2 TR-E G2070722 VER. A 103- A B2
D 8004 DIODE HZM4.7NB2 TR-E G2070782 VER. D 103- A B2
D 8005 DIODE BAS316 G2070716 1- A D3
D 8006 DIODE HSM88AS TR-E G2070170 1- A E3
D 8007 DIODE HSM88AS TR-E G2070170 1- A D2
D 8008 DIODE BAS316 G2070716 1- A D3
D 8009 DIODE HZM9.1NB3 TR-E G2070404 1- A F4
D 8010 DIODE BAS316 G2070716 1- A F4
D 8011 SURGE ABSORBER P6KA18A-E3 Q9000721 1-114 A G3
D 8011 SURGE ABSORBER P6KA18A-HE3 Q9000721A 115- A G3
D 8012 SURGE ABSORBER P6KA18A-E3 Q9000721 1-114 A G5
D 8012 SURGE ABSORBER P6KA18A-HE3 Q9000721A 115- A G5
D 8013 DIODE DSA3A1 G2090445 1- A F5
D 8014 SURGE ABSORBER RHCA-301Q43U Q9000827 1- A G1
D 8015 DIODE DSA3A1 G2090445 1- A F3
D 8016 DIODE DSA3A1 G2090445 1- A F5
D 8017 SURGE ABSORBER DSP201M-S00B Q9000375 1-
F 8001 CHIP FUSE 1A R429 001 Q0000089 1-71 A F5
F 8001 CHIP FUSE 1A 0466001.NR Q0000171 72- A F5
FB8001 M.RFC FBA03VA450AB-00 L1190389 1- A C4
FB8002 M.RFC FBA03VA450AB-00 L1190389 1- A C4
FB8003 M.RFC FBA03VA450AB-00 L1190389 1- A C5
J 8001 CONNECTOR TMP-J01X-V6 P1090210 1- A A5
J 8002 CONNECTOR IL-Y-11P-S15T2-E P0090653 1- A B4
J 8003 TERMINAL Y106 S5000179 1- A G4
J 8006 TERMINAL Y106 S5000179 1- A G5
L 8001 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- A A4
L 8002 CHIP COIL 0.064uH LQW31HN64NJ03L L1690258 1- A A3
L 8003 CHIP COIL 0.023uH LQW31HN23NJ03L L1690252 1- A A3
L 8004 COIL 0.015uH AS0803-15NK L0022536 1-90 A C3
L 8004 COIL 0.015uH TAS0803-15NK L0023103 91- A C3
L 8005 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A F2
L 8006 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A E1
L 8007 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A F1
Q 8001 IC NJM78L09UA-TE2 G1091305 1- A B4
Q 8002 TRANSISTOR DTC144EE TL G3070075 1- A B4
Q 8003 TRANSISTOR 2SC5415E-TD-E G3354158E 1-130 A A3
Q 8003 TRANSISTOR 2SC5415AE-TD-E G3070426 131- A A3
Q 8004 TRANSISTOR 2SA1179N6-CPA-TB G3111797F 1- A B4
Q 8005 TRANSISTOR DTC144EE TL G3070075 1- A C5
Q 8006 TRANSISTOR FMG2 T148 G3070015 1- A D3
Q 8007 IC S-AU93 G1094180 VER. D 1-23 A A1
Q 8007 IC S-AU93 G1094203 VER. D 24-47 A A1
Q 8007 IC S-AU93A(VX.Q) G1094616 VER. D
48-104
AA1
Q 8007 IC RA60H4452M1 G1094520 VER. D 105- A A1
Q 8007 IC S-AU82L G1093918 VER. A 1-52 A A1
Q 8007 IC S-AU82AL(VX.Q) G1094680 VER. A
53-102
AA1
Q 8007 IC RA60H4047M1-101 G1094556 VER. A 103- A A1
Q 8008 TRANSISTOR 2SC2812-5-TB-E G3328127E 1- A F4
Q 8018 IC LM2904PWR G1094010 1- A D3
R 8001 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A5
R 8002 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A4
R 8004 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A4
R 8006 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A A4
R 8007 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A A4
R 8008 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B4
R 8009 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A A4
R 8010 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B4
R 8011 CHIP RES. 10 1/8W 5% RMC1/8T 100J J24215100 VER. A 1- A A4
R 8011 CHIP RES. 12 1/8W 5% RMC1/8T 120J J24215120 VER. D 1- A A4
R 8012 CHIP RES. 4.7 1/4W 5% RMC1/4 4R7JATP J24245479 1- A B3
R 8014 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A A3
R 8015 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 VER. A 1-22 A D3
R 8015 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 VER. D 1-22 A D3
R 8015 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 23- A D3
R 8016 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- A B2
R 8017 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 VER. A 1- A B2
R 8017 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 VER. D 1- A B2
R 8019 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 VER. D 1- A B2
R 8020 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A D3
R 8021 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C5
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE
LAY ADR
To Next Page
