L-5

PA-2 Unit (Lot. 21~)

Parts List

VXR-9000 UHF Service Manual

PCB with Components (w/o Q8007 PA Module) CB3195001 VER. A

CB3195002 VER. D

C 8001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 8002 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 8003 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B4

C 8004 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 8005 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B4

C 8006 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 8007 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B4

C 8008 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A4

C 8009 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A4

C 8010 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 8011 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 8012 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B4

C 8013 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A4

C 8014 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B4

C 8015 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B4

C 8016 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A B4

C 8018 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A4

C 8019 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 8020 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A A4

C 8021 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 8022 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B4

C 8023 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 8024 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A A3

C 8025 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 8027 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A A3

C 8028 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A3

C 8029 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 8030 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 8031 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3

C 8032 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A B2

C 8033 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A C2

C 8034 CHIP CAP. 100pF 500V CH CF316CH101J500AT K22271267 1- A C2

C 8035 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 8036 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3

C 8037 CHIP CAP. 0.001uF 630V R GRM31BR32J102KY01L K22281801 1-84 A C2

C 8037 CHIP CAP. 0.001uF 630V UJ GRM31A7U2J102JW31D K22281803 85- A C2

C 8038 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 8039 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3

C 8041 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A E3

C 8043 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 8044 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A D2

C 8045 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1-47 A D3

C 8045 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 48- A D3

C 8046 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E3

C 8047 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D2

C 8048 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E3

C 8049 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3

C 8050 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E3

C 8051 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E3

C 8052 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E2

C 8053 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 8054 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 8055 FILM CAP. 7pF 500V UC232H0070D-T K33279046 1-52 A F2

C 8055 FILM CAP. 7pF 500V UC232H0070D-T K33279046 VER. D 53- A F2

C 8056 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A F4

C 8057 FILM CAP. 10pF 500V UC232H0100D-T K33279019 1- A E1

C 8058 FILM CAP. 10pF 500V UC232H0100D-T K33279019 1- A F1

C 8059 FILM CAP. 5pF 500V UC232H0050D-T K33279010 1- A G1

C 8060 FILM CAP. 2pF 500V UC232H0020D-T K33279043 VER. A 53- A F1

C 8063 CHIP CAP. 100pF 500V CH CF316CH101J500AT K22271267 1- A G1

C 8064 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G3

C 8065 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G5

C 8066 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G3

C 8067 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G5

C 8068 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B2

C 8069 CHIP CAP. 100pF 500V CH CF316CH101J500AT K22271267 1- A D2

C 8084 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G3

C 8085 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G5

C 8086 FILM CAP. 1pF 500V UC232H0010D-T K33279036 VER. D 48-

D 8001 DIODE RN739F T106 G2070626 1- A A4

D 8002 DIODE BAS316 G2070716 1- A A4

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
