K-11
PA Unit (Lot. 1~20)
Parts List
VXR-9000 UHF Service Manual
D 5009 SURGE ABSORBER RHCA-201Q43U Q9000825 5- A G1
D 5010 DIODE HZM9.1NB3 TR-E G2070404 1- A F4
D 5011 DIODE MC2848-T111-1 G2070694 1- A G3
F 5001 CHIP FUSE 1A R429 001 Q0000089 1- A B1
FB5001 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5002 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5003 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5004 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5005 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5006 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5007 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5008 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5009 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5010 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5011 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5012 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5013 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5014 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5015 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
FB5016 FERRITE BEADS 4A2 RI3X3-1 L9190001 1-
J 5001 CONNECTOR TMP-J01X-V6 P1090210 1- A A5
J 5002 CONNECTOR IL-Y-11P-S15T2-E P0090653 1- A B4
J 5003 TERMINAL Y106 S5000179 1- A G3
J 5004 TERMINAL Y106 S5000179 1- A G4
JP5001 WIRE ASSY GRN 20 2/2 T50502000 1-2
L 5001 CHIP COIL 0.0147uH LQW31HN15NJ03L L1690251 1- A A4
L 5002 M.RFC 0.0125uH C3328A-12NG-RA-T25H L1691077 1- A B4
L 5003 M.RFC 0.11uH 2% C6342A-R11G-RA L1691087 1- A C2
L 5005 M.RFC 0.05uH 2% C6342A-50NG-RA L1691084 1- A F2
L 5006 M.RFC 0.05uH 2% C6342A-50NG-RA L1691084 1- A F5
L 5007 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A G2
L 5008 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A H2
L 5010 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A G1
P 5001 WIRE ASSY RED 125 <7>/<7> T9318109 1-
P 5002 TERMINAL B5 AG M3 Q6000115 1-22
P 5002 TERMINAL B5 AG M3 Q6000115 23-
Q 5001 TRANSISTOR 2SC3357-T2 G3333577 1- A B4
Q 5002 TRANSISTOR 2SB1122S-TD G3211228S 1- A B4
Q 5003 IC NJM78L09UA-TE2 G1091305 1- A A3
Q 5004 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A B4
Q 5005 IC TA75S01F(TE85R.F) G1091593 1- A C5
Q 5006 TRANSISTOR DTC144EE TL G3070075 1- A A2
Q 5007 TRANSISTOR 2SB1132 T100 R G3211327R 1- A C5
Q 5008 FET PD55008TR G3070307 1- A F4
Q 5009 TRANSISTOR DTC144EE TL G3070075 1- A B5
Q 5010 TRANSISTOR 2SC2812-5-TB-E G3328127E 1- A B1
Q 5011 TRANSISTOR DTC144EE TL G3070075 1- A C5
Q 5012 IC TC4S66F(TE85R.F) G1090893 1- A C4
Q 5013 IC TC4S66F(TE85R.F) G1090893 1- A C4
Q 5014 TRANSISTOR 2SC4154-T111-1E G3341548E 1- A C5
Q 5015 FET PD55025STR G3070319 1-3 A E2
Q 5015 FET PD55025STR G3070319 4- A E2
Q 5016 FET PD55025STR G3070319 1-3 A E4
Q 5016 FET PD55025STR G3070319 4- A E4
R 5001 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A A4
R 5002 CHIP RES. 2.2 1/8W 5% RMC1/8T 2R2J J24215229 1- A B4
R 5003 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A A4
R 5004 CHIP RES. 4.7 1/4W 5% RMC1/4 4R7JATP J24245479 1- A B4
R 5005 CHIP RES. 22 1/16W 5% RMC1/16 220JATP J24185220 1- A A4
R 5006 CHIP RES. 180 1/16W 5% RMC1/16 181JATP J24185181 1- A A4
R 5007 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A C5
R 5008 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A B4
R 5009 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A4
R 5010 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B4
R 5012 CHIP RES. 15 1/16W 5% RMC1/16 150JATP J24185150 1- A B3
R 5013 CHIP RES. 10 1/2W 5% RMC1/2 100JCTP J24275100 1- A B4
R 5014 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- A B5
R 5015 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B5
R 5016 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 5017 CHIP RES. 51 1/2W 5% RMC1/2 510JTE J24275510 1- A B3
R 5018 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 5019 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B2
R 5020 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE
LAY ADR
To Next Page
