Vertex Standard VXR-9000 Service Manual

K-12
PA Unit (Lot. 1~20)
Parts List
VXR-9000 UHF Service Manual
R 5021 CHIP RES. 22 1/10W 5% RMC1/10T 220J J24205220 1- A A2
R 5022 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E2
R 5023 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B5
R 5024 CARBON FILM RES. 22k 1/6W 5% RD16PJ223 22K J01225223 1-2 A B5
R 5024 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 3- A B5
R 5026 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A D3
R 5027 CHIP RES. 1.5k 1/16W 5% RMC1/16 152JATP J24185152 1- A D3
R 5029 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E3
R 5030 CHIP RES. 5.6 1W 5% RMC1 5R6JTE J24305569 1- A C5
R 5031 CEMENT RES. 5.6 5W 10% ERF-5AK5R6 J30376569 1-61 A D1
R 5031 CEMENT RES. 5.6 5W 5% BWR5C5R6J J30375569 62- A D1
R 5033 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A E2
R 5034 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 5035 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A D1
R 5036 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A D5
R 5037 CHIP RES. 150 1/10W 5% RMC1/10T 151J J24205151 1- A G4
R 5038 CHIP RES. 1k 1/2W 5% RMC1/2 102JCTP J24275102 1- A E5
R 5039 CHIP RES. 1k 1/2W 5% RMC1/2 102JCTP J24275102 1- A E1
R 5040 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101 1- A H4
R 5041 CHIP RES. 18 1/2W 5% RMC1/2 180JTE J24275180 1- A E5
R 5042 CHIP RES. 18 1/2W 5% RMC1/2 180JTE J24275180 1- A E2
R 5043 METAL FILM RES. 1 3W 5% ERX-3SJ1R0 1 J22359044 1- A D3
R 5044 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 1- A G5
R 5045 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-2 A A3
R 5045 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 3- A A3
R 5046 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G3
R 5047 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G3
R 5048 METAL FILM RES. 1 3W 5% ERX-3SJ1R0 1 J22359044 1- A D3
R 5049 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A G1
R 5050 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B4
R 5051 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 1- A C5
R 5052 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C4
R 5055 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 3- A A5
R 5057 CHIP RES. 1.8k 1/10W 5% RMC1/10T 182J J24205182 1-2 A G5
R 5057 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 3- A G5
R 5060 CARBON FILM RES. 150k 1/6W 5% RD16PJ154 150K J01225154 1-2 A B1
R 5060 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 3- A B1
RL5001 RELAY DC12V ACP131 DC12V M1190152 1- A A2
S 5001 SLIDE SWITCH SSSS912N-2A-OR N6090094 1- A F4
TH5001 THERMISTOR 157-203-55009TP G9090045 1- A E5
TH5002 THERMISTOR 157-502-53002TP G9090049 1- A G4
VR5001 POT. 2.2k RH03A3AJ3X 2.2K J51807222 1- A C5
VR5002 POT. 2.2k RH03A3AJ3X 2.2K J51807222 1- A C4
SHIELD PLATE (PA) RA0506200 1-22
SHIELD PLATE (PA) RA0506200 23-
GASKET L=10 RA0515000 1-37
GASKET L=10 RA0515000 38-
LEAF SPRING R0120250 1-
LEAF SPRING R0120250 4-
LEAF SPRING R0140031 4-
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
