I-9

CNTL Unit

Parts List

VXR-9000 UHF Service Manual

PCB with Components CS2257409 DST: USA VER. A

CS2257410 DST: EXP VER. A

CS2257411 DST: USA VER. D

CS2257412 DST: EXP VER. D

CS2257414 DST: AUS VER. D

C 3001 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 3002 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3003 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3004 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3005 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3006 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 3007 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A1

C 3008 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d3

C 3009 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 3010 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3011 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 3012 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E3

C 3013 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d3

C 3014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 3015 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E3

C 3016 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 3017 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A A2

C 3018 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E3

C 3019 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 3020 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A1

C 3021 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- A A1

C 3022 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E3

C 3023 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3024 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3025 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3026 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3027 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3028 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A2

C 3029 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3030 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A2

C 3031 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- A A2

C 3032 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3033 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3034 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3035 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A A2

C 3036 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3037 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A1

C 3038 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- A A1

C 3039 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A2

C 3040 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A1

C 3041 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A1

C 3042 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A A2

C 3043 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B h2

C 3044 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B h2

C 3045 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A E3

C 3046 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B h2

C 3047 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 3049 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B h3

C 3050 AL.ELECTRO.CAP. 100uF 25V ECEV1EA101UP K48140013 1-24 B d3

C 3050 AL.ELECTRO.CAP. 100uF 25V EEE1EA101UP K48140018 25- B d3

C 3051 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e2

C 3052 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- B a1

C 3053 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 3054 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 3055 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c2

C 3056 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 3057 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b2

C 3058 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B a2

C 3059 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- B c3

C 3060 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B b3

C 3061 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G3

C 3062 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b3

C 3063 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A G3

C 3064 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A D2

C 3065 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b3

C 3066 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 1- B b3

C 3067 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F2

C 3068 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- B f1

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
