Vertex Standard VXR-9000 Service Manual

O-6
100W PA Unit (Option: Version D)
Parts List
VXR-9000 UHF Service Manual
C 6084 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A J1
C 6085 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A G2
C 6086 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A E2
C 6087 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C2
C 6088 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A E4
C 6089 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A F4
C 6090 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A E7
C 6091 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A F7
C 6092 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B1
C 6093 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A L6
C 6094 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A L7
C 6095 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B4
C 6096 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3
D 6001 DIODE RN739F T106 G2070626 1- A A4
D 6002 DIODE BAS316 G2070716 1- A B2
D 6003 LED SML-210VTT86 G2070768 1- A I2
D 6004 DIODE BAS316 G2070716 1- A B5
D 6005 LED SML-210VTT86 G2070768 1- A I2
D 6006 DIODE UDZS TE-17 5.6B G2070910 1- A E4
D 6007 DIODE UDZS TE-17 5.6B G2070910 1- A E7
D 6008 DIODE MC2850-T111-1 G2070704 1- A F5
D 6009 DIODE BAS316 G2070716 1- A A2
D 6010 DIODE MC2850-T111-1 G2070704 1- A F7
D 6011 DIODE MC2850-T111-1 G2070704 1- A B2
D 6012 DIODE 1SS319(TE85R.F) G2070080 1- A G4
D 6013 DIODE 1SS319(TE85R.F) G2070080 1- A G7
D 6014 DIODE BAS316 G2070716 1- A A2
D 6015 DIODE 1SS319(TE85R.F) G2070080 1- A J5
D 6016 DIODE 1SS319(TE85R.F) G2070080 1- A K6
D 6017 DIODE UDZS TE-17 5.6B G2070910 1- A B3
D 6019 LED SML-210VTT86 G2070768 1- A B2
D 6020 LED SML-210VTT86 G2070768 1- A B2
D 6021 DIODE DAN235K T97 G2070082 1- A B2
D 6022 DIODE UDZS TE-17 5.6B G2070910 1- A B2
D 6023 DIODE 1SS319(TE85R.F) G2070080 1- A L7
D 6024 DIODE BAS316 G2070716 1- A A2
D 6025 DIODE 1SS400 TE61 G2070634 1- A J6
F 6001 CHIP FUSE 15A 451 015.MR 15A Q0000105 1- A I2
F 6002 CHIP FUSE 15A 451 015.MR 15A Q0000105 1- A I2
FB6001 M.RFC FBA03VA450AB-00 L1190389 1-
FB6002 M.RFC FBA03VA450AB-00 L1190389 1-
FB6003 M.RFC FBA03VA450AB-00 L1190389 1-
J 6001 CONNECTOR TMP-S01X-C1 P1091254 1- A A4
J 6002 TERMINAL Y106 S5000179 1- A L2
J 6003 CONNECTOR IL-Y-11P-S15T2-E P0090653 1- A B2
JP6001 WIRE ASSY RED 125 <7>/<7> T9318109 1-
JP6002 WIRE ASSY RED 145 <7>/<7> T9318176 1-
L 6001 M.RFC 0.0015uH HK1608 1N5S-T L1690506 1- A A5
L 6002 CHIP COIL 0.064uH LQW31HN64NJ03L L1690258 1- A B5
L 6003 CHIP COIL 0.023uH LQW31HN23NJ03L L1690252 1- A B5
L 6004 CHIP COIL 0.022uH 2% C2520C-22NG-RA L1691286 1- A C5
L 6005 CHIP COIL 0.022uH 2% C2520C-22NG-RA L1691286 1- A C6
L 6006 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A M5
L 6007 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A M6
L 6008 COIL C1 1.0T6.0D1.6PEW R L0022694 1- A M6
Q 6001 IC NJM78L09UA-TE2 G1091305 1- A B2
Q 6002 TRANSISTOR FMG2 T148 G3070015 1- A B3
Q 6003 TRANSISTOR UMZ2N TR G3070117 1- A B2
Q 6004 TRANSISTOR 2SC5415E-TD-E G3354158E 1- A B5
Q 6005 TRANSISTOR 2SA812-T2B M5B G3108127E 1- A B3
Q 6006 TRANSISTOR DTC144EE TL G3070075 1- A B3
Q 6007 TRANSISTOR DTC144EE TL G3070075 1- A B3
Q 6008 TRANSISTOR UMZ2N TR G3070117 1- A B3
Q 6009 TRANSISTOR FMG2 T148 G3070015 1- A B3
Q 6010 TRANSISTOR FMG2 T148 G3070015 1- A B3
Q 6011 IC S-AU93 G1094203 1-7 A D3
Q 6011 IC S-AU93A(VX.Q) G1094616 8- A D3
Q 6012 IC LM2902PWR G1094009 1- A B3
Q 6013 IC LM2904PWR G1094010 1- A A2
Q 6014 IC S-AU93 G1094203 1-7 A D6
Q 6014 IC S-AU93A(VX.Q) G1094616 8- A D6
Q 6015 TRANSISTOR 2SA812-T2B M5B G3108127E 1- A I2
Q 6016 TRANSISTOR 2SA812-T2B M5B G3108127E 1- A H2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
