100W PA Unit (Option: Version D)

Parts List

VXR-9000 UHF Service Manual

PCB with Components (w/o Q6011 & Q6014 PA Module) CS1866001 VER. D

C 6001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A J1

C 6002 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A1

C 6003 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B2

C 6004 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 6005 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A1

C 6006 CHIP CAP. 0.001uF 630V R GRM31BR32J102KY01L K22281801 1-9 A K1

C 6006 CHIP CAP. 0.001uF 630V UJ GRM31A7U2J102JW31D K22281803 10- A K1

C 6007 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B2

C 6008 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 6009 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 6010 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A5

C 6011 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A K1

C 6012 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 6013 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A I1

C 6014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 6015 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A H2

C 6016 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B2

C 6017 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B2

C 6018 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A5

C 6019 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A B3

C 6021 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 6022 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B4

C 6023 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A A5

C 6024 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A C3

C 6025 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B5

C 6027 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 6028 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B5

C 6029 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B5

C 6032 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B5

C 6034 CHIP CAP. 9pF 50V CH GRM1882C1H9R0CZ01D K22174247 1- A B6

C 6036 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A C5

C 6037 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A C6

C 6041 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B3

C 6042 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A E4

C 6043 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E4

C 6044 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E7

C 6045 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A E7

C 6046 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A F4

C 6047 CHIP CAP. 0.001uF 630V R GRM31BR32J102KY01L K22281801 1-9 A F4

C 6047 CHIP CAP. 0.001uF 630V UJ GRM31A7U2J102JW31D K22281803 10- A F4

C 6048 CHIP CAP. 0.001uF 630V R GRM31BR32J102KY01L K22281801 1-9 A F7

C 6048 CHIP CAP. 0.001uF 630V UJ GRM31A7U2J102JW31D K22281803 10- A F7

C 6049 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A F7

C 6050 CHIP CAP. 0.22uF 10V B GRM188B11A224KA01D K22104801 1- A A2

C 6051 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A F5

C 6052 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A F7

C 6053 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A2

C 6055 CHIP CAP. 1pF 200V CK GRM2194C2D1R0CY21D K22230208 1- A G4

C 6056 CHIP CAP. 1pF 200V CK GRM2194C2D1R0CY21D K22230208 1- A G4

C 6057 CHIP CAP. 1pF 200V CK GRM2194C2D1R0CY21D K22230208 1- A G7

C 6058 CHIP CAP. 1pF 200V CK GRM2194C2D1R0CY21D K22230208 1- A G7

C 6059 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2

C 6061 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F4

C 6062 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F7

C 6063 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1-6 A A2

C 6063 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 7- A A2

C 6064 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A J5

C 6065 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A3

C 6066 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A J5

C 6067 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 6068 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A K6

C 6069 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 6070 FILM CAP. 6pF 500V UC232H0060D-T K33279045 1- A M5

C 6071 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A K6

C 6072 CHIP CAP. 10pF 500V CH ERE22X6C2H100JD01L K22273217 1- A M6

C 6074 CHIP CAP. 10pF 500V CH ERE22X6C2H100JD01L K22273217 1- A M6

C 6076 FILM CAP. 6pF 500V UC232H0060D-T K33279045 1- A M7

C 6077 CHIP CAP. 0.001uF 630V R GRM31BR32J102KY01L K22281801 1-9 A M8

C 6077 CHIP CAP. 0.001uF 630V UJ GRM31A7U2J102JW31D K22281803 10- A M8

C 6080 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A A5

C 6082 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A L2

C 6083 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A J1

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE
