J-5

PANEL Unit

Parts List

VXR-9000 UHF Service Manual

PCB with Components CB2328002 DST: USA

CB2328003 DST: EXP

CB2328004 DST: AUS

C 4001 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B c3

C 4002 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 4003 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 4004 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 4005 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 4006 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 4007 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 4008 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4009 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4010 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4011 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4012 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4013 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4014 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4015 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 4024 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 4025 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B b3

C 4026 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- B d3

C 4027 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B d3

C 4028 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-45 B e3

C 4028 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 AUS 46-47 B e3

C 4028 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 AUS 48- B e3

C 4028 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 EXP 46-47 B e3

C 4028 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 EXP 48- B e3

C 4028 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 USA 46-47 B e3

C 4028 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 USA 48- B e3

C 4029 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-45 B e3

C 4029 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 AUS 46-47 B e3

C 4029 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 AUS 48- B e3

C 4029 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 EXP 46-47 B e3

C 4029 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 EXP 48- B e3

C 4029 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 USA 46-47 B e3

C 4029 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 USA 48- B e3

C 4030 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e3

C 4031 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-45 B e3

C 4031 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 AUS 46-47 B e3

C 4031 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 AUS 48- B e3

C 4031 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 EXP 46-47 B e3

C 4031 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 EXP 48- B e3

C 4031 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 USA 46-47 B e3

C 4031 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 USA 48- B e3

C 4032 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-45 B e3

C 4032 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 AUS 46-47 B e3

C 4032 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 AUS 48- B e3

C 4032 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 EXP 46-47 B e3

C 4032 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 EXP 48- B e3

C 4032 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 USA 46-47 B e3

C 4032 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 USA 48- B e3

C 4033 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 4034 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B e3

C 4035 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-45 B e3

C 4035 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 AUS 46-47 B e3

C 4035 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 AUS 48- B e3

C 4035 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 EXP 46-47 B e3

C 4035 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 EXP 48- B e3

C 4035 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 USA 46-47 B e3

C 4035 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 USA 48- B e3

C 4036 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- B e3

C 4037 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2

C 4038 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e3

C 4039 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B d2

C 4040 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c1

C 4043 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b2

C 4044 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d2

C 4046 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 4047 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f3

C 4048 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d2

C 4049 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f3

C 4051 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 4052 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c1

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
