Vertex Standard VXR-9000 Service Manual

J-8
PANEL Unit
Parts List
VXR-9000 UHF Service Manual
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
R 4071 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B c2
R 4072 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B c2
R 4073 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A F2
R 4074 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A F2
S 4001 TACT SWITCH SKQMAL N5090105 1-62 A C2
S 4001 TACT SWITCH SKQMBBE010 N5090164 63- A C2
S 4002 TACT SWITCH SKQMAL N5090105 1-62 A B3
S 4002 TACT SWITCH SKQMBBE010 N5090164 63- A B3
S 4003 TACT SWITCH SKQMAL N5090105 1-62 A C3
S 4003 TACT SWITCH SKQMBBE010 N5090164 63- A C3
S 4004 TACT SWITCH SKQMAL N5090105 1-62 A B1
S 4004 TACT SWITCH SKQMBBE010 N5090164 63- A B1
S 4005 TACT SWITCH SKQMAL N5090105 1-62 A C1
S 4005 TACT SWITCH SKQMBBE010 N5090164 63- A C1
S 4006 TACT SWITCH SKQMAL N5090105 1-62 A B2
S 4006 TACT SWITCH SKQMBBE010 N5090164 63- A B2
VR4001 POT. RK09L1141 F1B A14 10KA J60800266 1- A E3
LED SPACER LH-3-6 S6000343 1-67
LED SPACER LH-5-5 S6000238 69-
LED SPACER LH-3-6 S6000343 1-67
LED SPACER LH-5-5 S6000238 69-
LED SPACER LH-3-8 S6000345 1-79
LED SPACER LH-5-7 S6000240 80-
LED SPACER LH-3-8 S6000345 1-87
LED SPACER LH-5-7 S6000240 88-
