H-15

MAIN Unit

Parts List

VXR-9000 UHF Service Manual

C 1154 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. D 23- A C1

C 1155 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- B b2

C 1156 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b2

C 1157 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B2

C 1158 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2

C 1159 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1-20 A C1

C 1159 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 VER. A 21-22 A C1

C 1159 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 VER. A 23- A C1

C 1159 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 VER. D 21- A C1

C 1160 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- B e3

C 1161 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 1162 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 1163 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A B3

C 1164 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1-22 A C1

C 1164 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VER. A 23- A C1

C 1164 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 VER. D 23- A C1

C 1165 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C1

C 1166 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B c3

C 1167 CHIP CAP. 0.0012uF 50V B GRM188B11H122KA01D K22174826 1- B e4

C 1168 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A C1

C 1169 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B3

C 1171 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D3

C 1172 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D1

C 1173 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 1174 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A B3

C 1175 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-47 A B2

C 1175 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 48- A B2

C 1176 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B d3

C 1178 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D2

C 1179 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1-47 A B2

C 1179 CHIP CAP. 0.015uF 50V B GRM188B11H153KA01D K22174838 48- A B2

C 1180 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B c3

C 1181 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1-22 A C1

C 1181 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. A 23- A C1

C 1181 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 VER. D 23- A C1

C 1182 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2

C 1183 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A D1

C 1184 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B e4

C 1186 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A C1

C 1187 CHIP CAP. 68pF 50V CH GRM1882C1H680JA01D K22174231 1- A B3

C 1189 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e1

C 1190 CHIP CAP. 0.0047uF 50V B ECJ1VB1H472K K22179622 1-68 A B2

C 1190 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174817 69- A B2

C 1191 CHIP CAP. 0.0039uF 50V B GRM188B11H392KA01D K22174830 1- A B2

C 1192 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 1193 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e4

C 1194 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d1

C 1195 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B1

C 1196 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 1197 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A D1

C 1198 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e4

C 1199 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B1

C 1200 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d1

C 1202 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B1

C 1203 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E1

C 1204 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A D1

C 1205 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c1

C 1206 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A E1

C 1207 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b1

C 1208 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A E1

C 1209 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B1

C 1210 CHIP CAP. 0.012uF 50V B GRM188B11H123KA01D K22174825 1- A B2

C 1211 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- A B2

C 1212 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- B d1

C 1213 CHIP CAP. 0.033uF 16V B ECJ1VB1C333K K22129515 1-87 A B2

C 1213 CHIP CAP. 0.033uF 16V B GRM188B11C333KA01D K22124812 88- A B2

C 1214 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174827 1- A B2

C 1215 CHIP CAP. 56pF 50V CH GRM1882C1H560JA01D K22174229 1- A B2

C 1216 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d1

C 1218 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b1

C 1219 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b1

C 1221 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A B2

C 1222 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d1

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
