H-16

MAIN Unit

Parts List

VXR-9000 UHF Service Manual

C 1223 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c1

C 1224 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c1

C 1225 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b1

C 1226 CHIP CAP. 82pF 50V CH GRM1882C1H820JA01D K22174233 1- A E1

C 1227 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c1

C 1228 CHIP CAP. 56pF 50V CH GRM1882C1H560JA01D K22174229 1- A A1

C 1229 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A1

C 1230 CHIP CAP. 180pF 50V CH GRM1882C1H181JA01D K22174241 1-21 A E1

C 1230 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 22-91 A E1

C 1230 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 92- A E1

C 1231 CHIP CAP. 180pF 50V CH GRM1882C1H181JA01D K22174241 1-21 A E1

C 1231 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 22-91 A E1

C 1231 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 92- A E1

C 1232 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b1

C 1234 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E1

C 1235 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c1

C 1236 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B c1

C 1237 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b1

C 1238 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A B1

C 1239 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A1

C 1240 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A B2

C 1241 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c1

C 1242 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 1244 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174833 1-22 A D1

C 1244 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER. A 23- A D1

C 1244 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174833 VER. D 23- A D1

C 1245 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B2

C 1246 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 1247 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E1

C 1249 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B c1

C 1250 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D1

C 1251 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B1

C 1252 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1-21 A D1

C 1252 CHIP CAP. 0.33uF 10V B GRM188B11A334KA61D K22104802 22-89 A D1

C 1254 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A1

C 1255 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-47 A D1

C 1255 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 48- A D1

C 1259 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A1

C 1260 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A B3

C 1262 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B1

C 1263 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A G1

C 1264 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G1

C 1265 CHIP TA.CAP. 1.5uF 16V TEESVA1C155M8R K78120020 1- A F2

C 1266 CHIP CAP. 0.033uF 16V R GRM188R11C333KA01D K22124801 1- A F1

C 1267 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A1

C 1270 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g4

C 1271 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A3

C 1272 CHIP TA.CAP. 0.1uF 35V TEESVA1V104M8R K78160025 1- A F2

C 1273 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A1

C 1274 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A G3

C 1275 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1-22 A G2

C 1275 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. A 23- A G2

C 1275 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 VER. D 23- A G2

C 1276 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B f3

C 1277 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 1-20 A G3

C 1277 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VER. A 21- A G3

C 1277 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 VER. D 21-24 A G3

C 1277 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VER. D 25- A G3

C 1278 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 1-20 A G3

C 1278 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VER. A 21-22 A G3

C 1278 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 VER. D 21-22 A G3

C 1278 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 23-25 A G3

C 1278 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 VER. A 26- A G3

C 1278 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 VER. D 26- A G3

C 1281 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F1

C 1282 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f3

C 1283 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 VER. A 23-26 A G4

C 1283 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 VER. A 27- A G4

C 1283 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. D 25- A G4

C 1284 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 VER. A 23- A G3

C 1285 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A G4

C 1285 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 3-22 A G4

C 1285 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VER. A 23- A G4

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
