H-17

MAIN Unit

Parts List

VXR-9000 UHF Service Manual

C 1285 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 VER. D 23-24 A G4

C 1285 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VER. D 25- A G4

C 1286 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A G3

C 1286 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 3-22 A G3

C 1286 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VER. A 23- A G3

C 1286 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 VER. D 23-24 A G3

C 1286 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VER. D 25- A G3

C 1287 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F1

C 1288 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G1

C 1289 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A F1

C 1290 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A4

C 1291 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- A E1

C 1292 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A G3

C 1293 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A G3

C 1294 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G1

C 1295 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A G1

C 1296 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A F3

C 1297 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A F3

C 1298 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E1

C 1299 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A F1

C 1300 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A A3

C 1301 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A G1

C 1302 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A F3

C 1303 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A F3

C 1304 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E1

C 1305 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1-3 A F1

C 1305 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 VER. A 21- A F1

C 1305 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 VER. D 4-10 A F1

C 1305 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 VER. D 11- A F1

C 1306 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G1

C 1307 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A A3

C 1308 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F4

C 1309 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F3

C 1310 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- B b4

C 1311 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- B b2

C 1312 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 1313 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B f2

C 1314 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A A3

C 1315 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f2

C 1316 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A F3

C 1317 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A F3

C 1318 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G2

C 1319 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B a1

C 1320 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A B3

C 1321 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A G2

C 1322 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a1

C 1323 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A2

C 1324 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A B3

C 1325 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a1

C 1326 CHIP CAP. 0.0033uF 50V B GRM188B11H332KA01D K22174831 1- B g2

C 1327 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 1328 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a2

C 1330 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B g2

C 1331 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F3

C 1332 AL.ELECTRO.CAP. 22uF 16V ECEV1CA220SR K48120002 1-25 A B3

C 1332 AL.ELECTRO.CAP. 22uF 16V EEE1CA220SR K48120024 26- A B3

C 1333 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d3

C 1334 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2

C 1335 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d3

C 1336 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1337 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F2

C 1338 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F3

C 1339 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A F3

C 1340 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A F2

C 1341 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1342 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- A A3

C 1343 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- A E2

C 1344 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A F3

C 1345 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- B g3

C 1346 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d4

C 1347 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2

C 1348 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E2

C 1349 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A F3

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
