H-18

MAIN Unit

Parts List

VXR-9000 UHF Service Manual

C 1350 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- A A2

C 1351 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B d4

C 1352 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2

C 1353 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A A5

C 1354 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A A4

C 1355 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A A5

C 1356 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A A4

C 1357 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A A5

C 1358 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B4

C 1359 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B5

C 1360 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A5

C 1361 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A4

C 1362 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1363 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1364 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1365 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1366 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1367 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1368 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1369 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1370 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1371 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1372 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1373 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1374 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1375 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1376 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1377 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1378 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1379 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 1380 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1381 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1382 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A5

C 1383 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1-20 A G3

C 1383 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VER. A 21-22 A G3

C 1383 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. A 23- A G3

C 1383 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 VER. D 21-24 A G3

C 1383 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. D 25- A G3

C 1384 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1-3 A G3

C 1384 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 VER. A 21-22 A G3

C 1384 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. A 23-30 A G3

C 1384 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. A 31- A G3

C 1384 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. D 4-24 A G3

C 1385 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B b2

C 1386 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a3

C 1387 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a2

C 1390 CHIP CAP. 0.0039uF 50V B GRM188B11H392KA01D K22174830 1- A C4

C 1391 CHIP CAP. 0.0068uF 50V B GRM188B11H682KA01D K22174834 1- A C4

C 1392 CHIP CAP. 0.0033uF 50V B GRM188B11H332KA01D K22174831 1- A C4

C 1393 CHIP TA.CAP. 47uF 4V SK7-0G476M-RA K78060048 1- B d3

C 1394 CHIP TA.CAP. 47uF 4V SK7-0G476M-RA K78060048 1- B e4

C 1395 CHIP TA.CAP. 47uF 4V SK7-0G476M-RA K78060048 1- B d3

C 1396 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 1397 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1-2 A G3

C 1397 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 VER. A 31-32 A G3

C 1398 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 3-20 A G3

C 1398 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. A 21-26 A G3

C 1398 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. A 27- A G3

C 1398 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 VER. D 21-24 A G3

C 1399 TANTALUM CAP. 47uF 6.3V DN0J470M1S K70087476 3-22 A D3

C 1399 CHIP TA.CAP. 47uF 6.3V TEESVA0J476M8R K78080085 VER. A 23-24 A D3

C 1399 TANTALUM CAP. 47uF 6.3V DN0J470M1S K70087476 VER. D 23-24 A D3

C 1399 CHIP TA.CAP. 47uF 6.3V TEESVA0J476M8R K78080085 25- A D3

C 1400 TANTALUM CAP. 47uF 6.3V DN0J470M1S K70087476 3-22 A D3

C 1400 CHIP TA.CAP. 47uF 6.3V TEESVA0J476M8R K78080085 VER. A 23-24 A D3

C 1400 TANTALUM CAP. 47uF 6.3V DN0J470M1S K70087476 VER. D 23-24 A D3

C 1400 CHIP TA.CAP. 47uF 6.3V TEESVA0J476M8R K78080085 25- A D3

C 1401 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. A 21-22 A C1

C 1401 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 VER. A 23- A C1

C 1401 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. D 11- A C1

C 1402 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 11-22 B b3

C 1402 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER. A 23-24 B b3

C 1402 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 VER. D 23-24 B b3

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE
