MAIN Unit

Parts List

VXR-9000 UHF Service Manual

C 1402 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 25- B b3

C 1403 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 11-22 B b2

C 1403 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER. A 23-24 B b2

C 1403 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 VER. D 23-24 B b2

C 1403 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 25- B b2

C 1404 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 11-22 B b1

C 1404 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER. A 23-24 B b1

C 1404 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 VER. D 23-24 B b1

C 1404 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 25- B b1

C 1405 CHIP CAP. 100pF 50V CH GRM2162C1H101JA01D K22170235 11-22 B b3

C 1405 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 VER. A 23-24 B b3

C 1405 CHIP CAP. 100pF 50V CH GRM2162C1H101JA01D K22170235 VER. D 23-24 B b3

C 1405 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 25- B b3

C 1406 CHIP CAP. 100pF 50V CH GRM2162C1H101JA01D K22170235 11-22 B b3

C 1406 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 VER. A 23-24 B b3

C 1406 CHIP CAP. 100pF 50V CH GRM2162C1H101JA01D K22170235 VER. D 23-24 B b3

C 1406 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 25- B b3

C 1407 CHIP CAP. 0.33uF 10V B GRM188B11A334KA61D K22104802 22 A E1

C 1407 CHIP CAP. 0.33uF 10V B GRM188B11A334KA61D K22104802 VER. A 23- A E1

C 1407 CHIP CAP. 0.33uF 10V B GRM188B11A334KA61D K22104802 VER. D 23- A E1

C 1408 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. A 27-

C 1408 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. D 25-38

C 1451 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. A 21-22 A G3

C 1451 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 VER. D 25- A G3

C 1452 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VER. A 21-

C 1453 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VER. A 21-

C 1455 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 VER. A 23-24 B f2

C 1455 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 25- B f2

C 1456 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 VER. A 23-24 A D2

C 1456 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 25- A D2

C 1501 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 3- B c3

C 1502 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 3- B c2

C 1503 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 3- B c2

C 1504 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 3- B c2

C 1505 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 3- B c2

C 1506 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 3- B d2

C 1508 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 3- B d2

C 1510 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 3- B c1

C 1511 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 VER. A 23-24 B c2

C 1511 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 25- B c2

C 1512 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 3- B c2

C 1513 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 3- B c2

C 1514 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 3- B c2

C 1515 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 3- B c2

C 1515 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 16-22 B c2

C 1515 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VER A 23-24 B c2

C 1515 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 25- B c2

C 1517 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 3- B c1

C 1518 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 3- B c1

C 1520 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 3- B c1

C 1521 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 3- B c1

C 1522 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 3- B c2

C 1527 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER A 23-24 A E1

C 1527 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 25- A E1

C 1528 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER A 23-24 A E1

C 1528 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 25- A E1

C 1529 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VER A 23-24 B c1

C 1529 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 25- B c1

C 1530 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 VER A 23-24 B d2

C 1530 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 25- B d2

C 1532 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 VER A 23-24 B c1

C 1532 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 25- B c1

C 1534 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 VER A 23-24 A E2

C 1534 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 25- A E2

CD1001 CERAMIC DISC CDBLA455KCAY07-B0 H7900180 1- A E1

CF1001 CERAMIC FILTER CFWLB455KGFA-B0 H3900399 1- A F1

CF1002 CERAMIC FILTER CFWLB455KFFA-B0 H3900395 1- A F1

D 1001 DIODE 1SS302(TE85R.F) G2070088 1- A G4

D 1002 DIODE RN739F T106 G2070626 1- A G4

D 1003 DIODE HVU350 TRF-E G2070380 1- A G5

D 1004 DIODE HVU350 TRF-E G2070380 1- A F5

D 1005 DIODE HVU350 TRF-E G2070380 1- A E5

D 1006 DIODE HZU5ALL-TRF-E G2070754 1- B e2

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR

Brand	Vertex Standard
Model	VXR-9000
Category	Repeater
Language	English

Vertex Standard VXR-9000 Service Manual
