Vertex Standard VXR-9000 Service Manual

H-20
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
D 1007 DIODE HVU350 TRF-E G2070380 1- A E5
D 1008 DIODE 1SV282(TPH3.F) G2070778 1- A C1
D 1009 DIODE 1SV282(TPH3.F) G2070778 1- A C1
D 1010 DIODE HVU350 TRF-E G2070380 1- A C1
D 1011 DIODE HZM5.6NB2 TR-E G2070722 1- B d3
D 1012 DIODE MA142WK-(TX) G2070534 1-94 B b1
D 1012 DIODE DA3J103E0L G2071346 95- B b1
D 1013 DIODE MA142WK-(TX) G2070534 1-94 B b1
D 1013 DIODE DA3J103E0L G2071346 95- B b1
D 1014 DIODE MA143-(TX) G2070536 1-126 A D1
D 1014 DIODE DA3J101F0L G2071354 127- A D1
D 1015 DIODE MA143-(TX) G2070536 1-126 A E1
D 1015 DIODE DA3J101F0L G2071354 127- A E1
D 1016 DIODE RN739F T106 G2070626 1- A B1
D 1017 DIODE RN739F T106 G2070626 1- A B1
D 1018 DIODE 1SV282(TPH3.F) G2070778 1- A G3
D 1019 DIODE 1SV282(TPH3.F) G2070778 1- A G3
D 1020 DIODE 1SV282(TPH3.F) G2070778 1- A G2
D 1021 DIODE 1SV282(TPH3.F) G2070778 1- A G2
D 1022 DIODE HZU5ALL-TRF-E G2070754 1- B b1
D 1023 DIODE MA143-(TX) G2070536 1-126 A C4
D 1023 DIODE DA3J101F0L G2071354 127- A C4
D 1024 DIODE MA143-(TX) G2070536 1-126 A C3
D 1024 DIODE DA3J101F0L G2071354 127- A C3
D 1025 DIODE MA143-(TX) G2070536 1-126 A B4
D 1025 DIODE DA3J101F0L G2071354 127- A B4
D 1026 DIODE MA143-(TX) G2070536 1-126 A B3
D 1026 DIODE DA3J101F0L G2071354 127- A B3
D 1501 DIODE 1SS321(TE85R.F) G2070076 16-22 B c2
D 1501 DIODE DAN235K T97 G2070082 VER. A 23-24 B c2
D 1501 DIODE DAN235K T97 G2070082 25- B c2
D 1502 DIODE 1SS321(TE85R.F) G2070076 16-22 B c1
D 1502 DIODE DAN235K T97 G2070082 VER. A 23-24 B c1
D 1502 DIODE DAN235K T97 G2070082 25- B c1
J 1001 CONNECTOR TMP-J01X-V6 P1090210 1- A G4
J 1002 CONNECTOR SB20-02WS P0090609 1- A A3
J 1003 CONNECTOR SB20-02WS P0090609 1- A A4
J 1004 CONNECTOR SB20-03WS P0090610 1- A A3
J 1005 CONNECTOR FH12-50S-0.5SV P1091092 1- A B4
J 1006 CONNECTOR SC25-02WS P0090621 1- A A2
J 1007 CONNECTOR TMP-J01X-V6 P1090210 1- A A1
JP1001 WIRE ASSY GRN 35 2/2 T50503500 1-2 B f1
JP1002 WIRE ASSY GRN 105 2/2 T50510500 1-2
JP1003 WIRE ASSY GRN 45 2/2 T50504500 1-2
L 1001 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- A G4
L 1002 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A C3
L 1003 COIL E2 0.35-1.6-4T-L L0022456 1-20 A F4
L 1003 COIL E2 0.35-1.6-4.5T-L L0022577 VER. A 21- A F4
L 1003 COIL E2 0.35-1.6-4T-L L0022456 VER. D 21- A F4
L 1004 COIL E2 0.35-1.6-4T-L L0022456 1-20 A F4
L 1004 COIL E2 0.35-1.6-4.5T-L L0022577 VER. A 21- A F4
L 1004 COIL E2 0.35-1.6-4T-L L0022456 VER. D 21- A F4
L 1005 M.RFC 0.015uH LL1608-F15NK L1690361 1- A F4
L 1006 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A C2
L 1007 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- A C2
L 1008 CHIP COIL 0.017uH LQW31HN17NJ03L L1690249 1- A F4
L 1009 CHIP COIL 0.47uH C2520C-R47J L1690552 1- A C2
L 1010 COIL E2 0.35-1.6-4T-L L0022456 1-20 A E4
L 1010 COIL E2 0.35-1.6-4.5T-L L0022577 VER. A 21- A E4
L 1010 COIL E2 0.35-1.6-4T-L L0022456 VER. D 21- A E4
L 1011 COIL E2 0.35-1.6-4T-L L0022456 1-20 A E4
L 1011 COIL E2 0.35-1.6-4.5T-L L0022577 VER. A 21- A E4
L 1011 COIL E2 0.35-1.6-4T-L L0022456 VER. D 21- A E4
L 1012 COIL E2 0.35-1.6-4T-L L0022456 1-20 A E5
L 1012 COIL E2 0.35-1.6-4.5T-L L0022577 VER. A 21- A E5
L 1012 COIL E2 0.35-1.6-4T-L L0022456 VER. D 21- A E5
L 1013 COIL E2 0.35-1.6-4T-L L0022456 1-20 A D5
L 1013 COIL E2 0.35-1.6-4.5T-L L0022577 VER. A 21- A D5
L 1013 COIL E2 0.35-1.6-4T-L L0022456 VER. D 21- A D5
L 1014 CHIP COIL 0.22uH C2520C-R22J L1690548 1- A E2
L 1015 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- B c3
L 1016 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- B c2
L 1017 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A C1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
