Vertex Standard VXR-9000 Service Manual

H-21
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
L 1018 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- B c2
L 1019 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A C1
L 1020 M.RFC 0.0185uH C3328A-18NG-RA-T25H L1691078 1-20 A C1
L 1020 M.RFC 0.028uH 2% C6328A-28NG-RA-T25H L1691081 VER. A 21-22 A C1
L 1020 M.RFC 0.0185uH C3328A-18NG-RA-T25H L1691078 VER. D 21- A C1
L 1021 CHIP COIL 0.68uH C2520C-R68J L1690554 1- A E2
L 1022 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A C1
L 1023 M.RFC 10uH LK2125 100K-T L1690331 1- B c3
L 1024 M.RFC 0.1uH LK2125 R10K-T L1690307 1- A D2
L 1024 M.RFC 0.1uH LK2125 R10K-T L1690307 16-22 A D2
L 1024 M.RFC 0.27uH LK2125 R27K-T L1690312 VER. A 23-24 A D2
L 1024 M.RFC 0.1uH LK2125 R10K-T L1690307 VER. D 23-24 A D2
L 1024 M.RFC 0.27uH LK2125 R27K-T L1690312 25- A D2
L 1025 CHIP COIL 0.33uH C2520C-R33J L1690550 1-3 A C1
L 1025 CHIP COIL 0.1uH C2520C-R10J L1690544 VER. A 21- A C1
L 1025 CHIP COIL 0.33uH C2520C-R33J L1690550 VER. D 4-10 A C1
L 1025 CHIP COIL 0.1uH C2520C-R10J L1690544 VER. D 11- A C1
L 1026 M.RFC 0.082uH HK1608 82NJ-T L1690527 1- A B1
L 1027 M.RFC 1uH 5% C2012C-1R0J L1691160 1- A E1
L 1029 M.RFC 0.33uH LK2125 R33K-T L1690313 1- A E1
L 1030 CHIP COIL 0.018uH C2520C-18NK L1690535 1- A B1
L 1031 M.RFC 0.012uH HK1608 12NJ-T L1690517 1- A A1
L 1032 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A G1
L 1033 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A G3
L 1034 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A G2
L 1035 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A G3
L 1036 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A G2
L 1037 M.RFC 0.022uH 2% C6328A-22NG-RA-T25H L1691080 1-20 A G3
L 1037 M.RFC 0.028uH 2% C6328A-28NG-RA-T25H L1691081 VER. A 21- A G3
L 1037 M.RFC 0.022uH 2% C6328A-22NG-RA-T25H L1691080 VER. D 21- A G3
L 1038 M.RFC 0.022uH 2% C6328A-22NG-RA-T25H L1691080 1-20 A G3
L 1038 M.RFC 0.028uH 2% C6328A-28NG-RA-T25H L1691081 VER. A 21- A G3
L 1038 M.RFC 0.022uH 2% C6328A-22NG-RA-T25H L1691080 VER. D 21- A G3
L 1039 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- A G1
L 1040 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A F4
L 1041 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A F3
L 1042 CHIP COIL 0.47uH C2520C-R47J L1690552 1- A G1
L 1043 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A F3
L 1044 CHIP COIL 0.33uH C2520C-R33J L1690550 1- A F2
L 1045 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A G1
L 1046 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A F3
L 1047 CHIP COIL 0.022uH C2520C-22NK L1690536 1- A F3
L 1048 M.RFC 0.022uH 2% C6328A-22NG-RA-T25H L1691080 VER. A 23- A C1
L 1451 M.RFC 0.027uH HK1608 27NJ-T L1690521 VER. A 21-
L 1452 M.RFC 0.027uH HK1608 27NJ-T L1690521 VER. A 21-
L 1453 M.RFC 0.027uH HK1608 27NJ-T L1690521 VER. A 21-
L 1454 M.RFC 0.027uH HK1608 27NJ-T L1690521 VER. A 21-
L 1501 CHIP COIL 0.22uH C2520C-R22J L1690548 3- B c2
L 1502 CHIP COIL 0.68uH C2520C-R68J L1690554 3- B c2
L 1503 M.RFC 0.1uH LK2125 R10K-T L1690307 3- B c2
L 1503 M.RFC 0.1uH LK2125 R10K-T L1690307 16-22 B c2
L 1503 M.RFC 0.27uH LK2125 R27K-T L1690312 VER. A 23-24 B c2
L 1503 M.RFC 0.27uH LK2125 R27K-T L1690312 25- B c2
L 1504 M.RFC 1uH 5% C2012C-1R0J L1691160 3- B c1
L 1504 M.RFC 0.56uH 5% C2012C-R56J L1691020 23- B c1
L 1505 M.RFC 4.7uH LK1608 4R7K-T L1690688 VER. A 23-24 B c3
L 1505 M.RFC 4.7uH LK1608 4R7K-T L1690688 25- B c3
L 1506 M.RFC 4.7uH LK1608 4R7K-T L1690688 VER. A 23-24 B c2
L 1506 M.RFC 4.7uH LK1608 4R7K-T L1690688 25- B c2
L 1507 M.RFC 4.7uH LK1608 4R7K-T L1690688 VER. A 23-24 B c2
L 1507 M.RFC 4.7uH LK1608 4R7K-T L1690688 25- B c2
L 1508 M.RFC 4.7uH LK1608 4R7K-T L1690688 VER. A 23-24 B c1
L 1508 M.RFC 4.7uH LK1608 4R7K-T L1690688 25- B c1
L 1509 M.RFC 4.7uH LK1608 4R7K-T L1690688 VER. A 23-24 B c1
L 1509 M.RFC 4.7uH LK1608 4R7K-T L1690688 25- B c1
L 1510 M.RFC 4.7uH LK1608 4R7K-T L1690688 VER. A 23-24 B c1
L 1510 M.RFC 4.7uH LK1608 4R7K-T L1690688 25- B c1
Q 1001 IC NJM2902V-TE1 G1091679 1- A C4
Q 1002 TRANSISTOR 2SD1664 T100 Q G3416647Q 1- B e3
Q 1003 IC TA75S01F(TE85R.F) G1091593 1- B e3
Q 1004 IC NJM2904V-TE1 G1091677 1- A D3
Q 1005 IC TAR5S30(TE85L.F) G1093570 1- B d1
Q 1006 IC M51132FP 600C G1091930 1- A D4
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
