Vertex Standard VXR-9000 Service Manual

H-22
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
Q 1007 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A C2
Q 1008 IC MB15A02PFV1-G-BND-EFE1 G1092541 1- A C2
Q 1009 TRANSISTOR 2SC3357-T2 RF G3333577F 1- A F4
Q 1010 IC NJM2904V-TE1 G1091677 1- B e4
Q 1012 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- B e2
Q 1013 TRANSISTOR UN5215-(TX) G3070193 1-99 B e2
Q 1013 TRANSISTOR DRC5114T0L G3070444 100- B e2
Q 1014 TRANSISTOR 2SA1162GR TE85R G3111627G 1- B e1
Q 1015 TRANSISTOR 2SC2712GR(TE85R.F) G3327127G 1- B e1
Q 1016 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B d2
Q 1017 IC NJM2902V-TE1 G1091679 1- A C4
Q 1018 IC SPM5001-TL-E G1093686 1-80 A E3
Q 1018 IC SPM5002-TL-E G1094899 81- A E3
Q 1019 TRANSISTOR 2SC3357-T2 RF G3333577F 1- B b2
Q 1020 IC NJM2904V-TE1 G1091677 1- A B3
Q 1021 FET 2SK508-T2B K52 A G3805087B 1- A C1
Q 1022 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- A D1
Q 1023 TRANSISTOR 2SC2812N6-CPA-TB-E G3328128F 1-124 B d3
Q 1023 TRANSISTOR MMBT6428LT1G G3070500 125- B d3
Q 1024 TRANSISTOR XN1213-(TX) G3070194 1-115 B e1
Q 1024 TRANSISTOR DMC261030L G3070445 116- B e1
Q 1025 IC NJM2902V-TE1 G1091679 1- A B2
Q 1026 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- A B1
Q 1027 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B d1
Q 1028 IC TA31136FNG(EL) G1091605 1-91 A E1
Q 1028 IC AA32416 G1094857 92- A E1
Q 1029 TRANSISTOR 2SB1122S-TD G3211228S 1- B d5
Q 1030 TRANSISTOR 2SC3357-T2 RF G3333577F 1- A A1
Q 1031 TRANSISTOR XN1213-(TX) G3070194 1-115 B d5
Q 1031 TRANSISTOR DMC261030L G3070445 116- B d5
Q 1032 TRANSISTOR UN5213-(TX) G3070192 1-104 B g1
Q 1032 TRANSISTOR DRC5144E G3070440 105- B g1
Q 1033 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A E1
Q 1034 TRANSISTOR 2SA1179N6-CPA-TB G3111797F 1- B g1
Q 1035 TRANSISTOR XN1213-(TX) G3070194 1-115 B b1
Q 1035 TRANSISTOR DMC261030L G3070445 116- B b1
Q 1036 TRANSISTOR XN1213-(TX) G3070194 1-115 B f1
Q 1036 TRANSISTOR DMC261030L G3070445 116- B f1
Q 1037 TRANSISTOR DTA144EE TL G3070074 1- B f1
Q 1039 TRANSISTOR XN1213-(TX) G3070194 1-115 B d1
Q 1039 TRANSISTOR DMC261030L G3070445 116- B d1
Q 1040 IC BU4066BCFV-E2 G1093537 1- B g3
Q 1041 TRANSISTOR 2SA1162GR TE85R G3111627G 1- B b1
Q 1042 TRANSISTOR 2SC2712GR(TE85R.F) G3327127G 1- B b1
Q 1043 TRANSISTOR DTC144EK T146 G3070033 1- B g4
Q 1044 TRANSISTOR FMG2 T148 G3070015 1- B g4
Q 1045 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A G1
Q 1046 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A F1
Q 1047 TRANSISTOR UN5215-(TX) G3070193 1-99 A F1
Q 1047 TRANSISTOR DRC5114T0L G3070444 100- A F1
Q 1048 FET 2SK508-T2B K52 A G3805087B 1- A F3
Q 1049 FET 2SK508-T2B K52 A G3805087B 1- A F3
Q 1050 IC NJM2904V-TE1 G1091677 1- A A3
Q 1051 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- A F1
Q 1052 IC MB15A02PFV1-G-BND-EFE1 G1092541 1- A G1
Q 1053 TRANSISTOR DTC144EE TL G3070075 1-3 B b4
Q 1053 TRANSISTOR RT1N441U-T11-1 G3070247 VER. A 21- B b4
Q 1053 TRANSISTOR DTC144EE TL G3070075 VER. D 4-10 B b4
Q 1053 TRANSISTOR RT1N441U-T11-1 G3070247 VER. D 11- B b4
Q 1054 TRANSISTOR DTC144EE TL G3070075 1-3 B b2
Q 1054 TRANSISTOR RT1N441U-T11-1 G3070247 VER. A 21- B b2
Q 1054 TRANSISTOR DTC144EE TL G3070075 VER. D 4-10 B b2
Q 1054 TRANSISTOR RT1N441U-T11-1 G3070247 VER. D 11- B b2
Q 1055 IC M62364FP 600D G1093033 1- B f2
Q 1056 IC M51132FP 600C G1091930 1- A B3
Q 1057 IC TDA2003V-PBF G1090769 1- A A2
Q 1058 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B b2
Q 1059 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- A F3
Q 1060 TRANSISTOR DTC144EE TL G3070075 1-3 B b2
Q 1060 TRANSISTOR RT1N441U-T11-1 G3070247 VER. A 21- B b2
Q 1060 TRANSISTOR DTC144EE TL G3070075 VER. D 4-10 B b2
Q 1060 TRANSISTOR RT1N441U-T11-1 G3070247 VER. D 11- B b2
Q 1061 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A E2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
