Vertex Standard VXR-9000 Service Manual

H-23
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
Q 1062 IC L78M05T-TL G1091731 1- B d3
Q 1501 TRANSISTOR XN1213-(TX) G3070194 3-115 B c1
Q 1501 TRANSISTOR DMC261030L G3070445 116- B c1
Q 1502 TRANSISTOR 2SC5226-4/5-TL G3352268Z 3- B c2
Q 1503 TRANSISTOR XN1213-(TX) G3070194 3- A E1
Q 1504 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 3- B c1
R 1001 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G4
R 1002 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A G5
R 1003 CHIP RES. 150 1W 5% RMC1 151JTE J24305151 1- B e3
R 1004 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D3
R 1005 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- B e3
R 1007 CHIP RES. 150 1W 5% RMC1 151JTE J24305151 1- B e3
R 1009 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- B e3
R 1010 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103 1- A C3
R 1011 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103 1- A C3
R 1012 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- B e3
R 1013 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D3
R 1014 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B e3
R 1016 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-2 A D3
R 1016 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 3- A D3
R 1017 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e3
R 1018 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F5
R 1019 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B d4
R 1020 CHIP RES. 680 1/16W 5% RMC1/16 681JATP J24185681 1- B d4
R 1021 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F5
R 1022 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- B d3
R 1023 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C4
R 1024 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D3
R 1025 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C3
R 1027 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D4
R 1029 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D3
R 1030 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A C2
R 1031 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D3
R 1032 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D4
R 1033 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A C2
R 1034 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A C3
R 1035 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F4
R 1036 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A C4
R 1037 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1-2 B d3
R 1037 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 3- B d3
R 1038 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F4
R 1039 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A F4
R 1040 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A C2
R 1041 CHIP RES. 56 1/16W 5% RMC1/16 560JATP J24185560 1- A C3
R 1042 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C2
R 1043 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A F5
R 1044 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1-56 A F5
R 1044 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 VER. A 57-89 A F5
R 1044 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 VER. A 90- A F5
R 1044 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 VER. D 57- A F5
R 1045 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C2
R 1046 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d3
R 1047 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A C4
R 1049 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D4
R 1050 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-22 A C5
R 1050 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 VER. A 23-52 A C5
R 1050 CHIP RES. 180k 1/16W 5% RMC1/16 184JATP J24185184 VER. A 53- A C5
R 1050 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 VER. D 23- A C5
R 1052 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C2
R 1053 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C2
R 1055 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D4
R 1056 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- B e4
R 1057 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C2
R 1060 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E5
R 1061 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B e2
R 1062 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e2
R 1063 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 1065 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E5
R 1066 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-22 B e2
R 1066 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 VER. A 23- B e2
R 1066 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 VER. D 23- B e2
R 1067 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-22 B e1
R 1067 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 VER. A 23- B e1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
