Vertex Standard VXR-9000 Service Manual

H-24
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
R 1067 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 VER. D 23- B e1
R 1069 CHIP RES. 180k 1/16W 5% RMC1/16 184JATP J24185184 1- A C5
R 1070 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e2
R 1071 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B e4
R 1072 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 1073 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B d4
R 1074 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B e4
R 1075 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- B d2
R 1076 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B d2
R 1077 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B e1
R 1078 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B e1
R 1080 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C4
R 1081 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A C4
R 1082 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B d2
R 1083 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 1084 CHIP RES. 680 1/16W 5% RMC1/16 681JATP J24185681 1- B e4
R 1085 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 1086 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B e2
R 1087 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B d1
R 1088 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B d1
R 1089 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B d1
R 1090 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e1
R 1092 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A C4
R 1093 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A D1
R 1094 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-2 B e4
R 1094 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 3 B e4
R 1094 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 VER. A 21-22 B e4
R 1094 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 VER. A 23-52 B e4
R 1094 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 VER. A 53- B e4
R 1094 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 VER. D 4-11 B e4
R 1094 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 VER. D 12-25 B e4
R 1094 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 VER. D 26- B e4
R 1095 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- A C4
R 1096 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1-22 B e4
R 1096 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 VER. A 23-50 B e4
R 1096 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 VER. A 51- B e4
R 1096 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 VER. D 23- B e4
R 1097 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A D1
R 1098 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A D1
R 1099 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B c3
R 1101 CHIP RES. 270k 1/16W 5% RMC1/16 274JATP J24185274 1- B e4
R 1102 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B c3
R 1104 CHIP RES. 56 1/16W 5% RMC1/16 560JATP J24185560 1- B c3
R 1105 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D1
R 1107 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 1- B e4
R 1108 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 A C4
R 1108 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- A C4
R 1108 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- A C4
R 1108 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- A C4
R 1109 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 A C4
R 1109 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- A C4
R 1109 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- A C4
R 1109 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- A C4
R 1110 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B e4
R 1112 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- B e4
R 1114 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D2
R 1115 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e4
R 1116 CHIP RES. 33 1/16W 5% RMC1/16 330JATP J24185330 1- A C1
R 1117 CHIP RES. 100 1/16W 1% RMC1/16 101FTP J24183101 1- A E3
R 1118 CHIP RES. 100 1/16W 1% RMC1/16 101FTP J24183101 1- A E3
R 1119 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1 A B3
R 1119 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 2-3 A B3
R 1119 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 4-91 A B3
R 1119 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 92- A B3
R 1121 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 A C3
R 1121 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- A C3
R 1121 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- A C3
R 1121 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- A C3
R 1122 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 A C3
R 1122 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- A C3
R 1122 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- A C3
R 1122 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- A C3
R 1123 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- B b2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
