Vertex Standard VXR-9000 Service Manual

H-25
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
R 1124 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A B3
R 1125 CHIP RES. 180 1/16W 5% RMC1/16 181JATP J24185181 1- A E2
R 1126 CHIP RES. 10 1/10W 5% RMC1/10T 100J J24205100 1- B c2
R 1127 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 1128 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B b2
R 1129 CHIP RES. 470k 1/16W 5% RMC1/16 474JATP J24185474 1- A B3
R 1130 CHIP RES. 33 1/16W 5% RMC1/16 330JATP J24185330 1- A C1
R 1131 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A D2
R 1133 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 B e4
R 1133 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- B e4
R 1133 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- B e4
R 1133 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- B e4
R 1134 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 B e4
R 1134 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- B e4
R 1134 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- B e4
R 1134 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- B e4
R 1135 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 1136 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A B3
R 1137 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A B3
R 1138 CHIP RES. 120k 1/16W 1% RMC1/16 124FTP J24183124 1- A B2
R 1139 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A C1
R 1140 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C1
R 1142 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-2 A E1
R 1142 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 3-15 A E1
R 1142 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 16-22 A E1
R 1142 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 VER A 23-24 A E1
R 1142 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 25- A E1
R 1143 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A D1
R 1146 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-45 B e3
R 1146 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 AUS 46- B e3
R 1146 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 EXP 46- B e3
R 1146 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 USA 46- B e3
R 1147 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- A B2
R 1148 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D2
R 1149 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A B3
R 1150 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A C1
R 1151 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- A C1
R 1152 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- A B2
R 1153 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B d2
R 1154 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1-22 A C1
R 1154 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 VER A 23- A C1
R 1154 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 VER D 23- A C1
R 1155 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- B e4
R 1156 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B2
R 1157 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A B1
R 1158 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A B1
R 1159 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B1
R 1160 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B e4
R 1161 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e4
R 1162 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B1
R 1163 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A E1
R 1164 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e1
R 1165 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- A B2
R 1166 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- A B2
R 1167 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B b1
R 1168 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- A B2
R 1169 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A B1
R 1170 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- A B2
R 1171 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A E1
R 1172 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A B1
R 1173 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A B1
R 1174 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- B d1
R 1175 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B d1
R 1176 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b1
R 1177 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b1
R 1178 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d5
R 1179 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 1- B c1
R 1180 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d5
R 1181 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A A1
R 1182 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- A A1
R 1183 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b1
R 1184 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b1
R 1185 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
