Vertex Standard VXR-9000 Service Manual

H-26
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
R 1186 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1-21 A E1
R 1186 CHIP RES. 180k 1/16W 5% RMC1/16 184JATP J24185184 22-91 A E1
R 1186 CHIP RES. 390k 1/16W 5% RMC1/16 394JATP J24185394 92- A E1
R 1187 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B d5
R 1188 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A B1
R 1189 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 1190 CHIP RES. 47 1/10W 5% RMC1/10T 470J J24205470 1- A A1
R 1191 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1-21 B c1
R 1191 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 22- B c1
R 1192 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d5
R 1193 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A B2
R 1194 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B b1
R 1195 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B g1
R 1196 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f1
R 1197 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B g1
R 1198 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1-21 B c1
R 1198 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 22- B c1
R 1199 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A E1
R 1200 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b1
R 1201 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B g1
R 1202 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A E1
R 1203 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- B c1
R 1204 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A B2
R 1205 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 1207 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-20 A B1
R 1207 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 VER. D 21- A B1
R 1209 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A E1
R 1210 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A E1
R 1212 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B d1
R 1214 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D1
R 1215 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A D1
R 1216 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A D1
R 1217 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D1
R 1219 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A B1
R 1220 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d1
R 1221 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B d1
R 1222 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 1- A D1
R 1223 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A B1
R 1224 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g4
R 1225 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B f3
R 1226 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A F1
R 1227 CHIP RES. 33 1/16W 5% RMC1/16 330JATP J24185330 1- A G3
R 1228 CHIP RES. 33 1/16W 5% RMC1/16 330JATP J24185330 1- A G2
R 1229 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 1230 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B b1
R 1230 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 VER. A 92- B b1
R 1230 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 VER. D 92- B b1
R 1231 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B b1
R 1231 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 VER. A 92- B b1
R 1231 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 VER. D 92- B b1
R 1232 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B a2
R 1233 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-18 B g3
R 1233 CHIP RES. 470k 1/16W 5% RMC1/16 474JATP J24185474 19- B g3
R 1234 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 1- A G1
R 1235 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 1- A G1
R 1236 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A F2
R 1236 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 VER. A 92- A F2
R 1236 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 VER. D 92- A F2
R 1237 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g4
R 1238 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g3
R 1239 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g3
R 1240 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g3
R 1241 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B b1
R 1242 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B a2
R 1243 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A F2
R 1244 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1- A A1
R 1245 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 1246 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B g3
R 1247 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-3 B b1
R 1247 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 VER. A 21- B b1
R 1247 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 VER. D 4-10 B b1
R 1247 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 VER. D 11- B b1
R 1248 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-3 B a1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
