Vertex Standard VXR-9000 Service Manual

H-27
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
R 1248 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 VER. A 21- B a1
R 1248 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 VER. D 4-10 B a1
R 1248 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 VER. D 11- B a1
R 1249 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- B g3
R 1250 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G1
R 1251 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1-20 A A1
R 1251 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 VER. D 21- A A1
R 1252 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1-20 A A1
R 1252 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 VER. D 21- A A1
R 1253 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A G1
R 1254 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A G1
R 1255 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1-20 A A1
R 1255 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 VER. D 21- A A1
R 1256 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F1
R 1257 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A A3
R 1258 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A A3
R 1259 CHIP RES. 56 1/16W 5% RMC1/16 560JATP J24185560 1- A G1
R 1260 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A A3
R 1261 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A E1
R 1262 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A E1
R 1263 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F1
R 1265 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A G1
R 1266 CHIP RES. 2.2k 1/16W 1% RMC1/16 222FTP J24183222 1- A B3
R 1267 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F1
R 1268 CHIP RES. 1.8k 1/16W 1% RMC1/16 182FTP J24183182 1- A A3
R 1269 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A A3
R 1270 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A F4
R 1271 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A F3
R 1272 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1-22 A F3
R 1272 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 VER. D 23- A F3
R 1273 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1-22 A F2
R 1273 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 VER. A 23- A F2
R 1273 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 VER. D 23- A F2
R 1274 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A F1
R 1277 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23- A F3
R 1280 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A G1
R 1281 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1-22 B f2
R 1281 CHIP RES. 1.5k 1/16W 5% RMC1/16 152JATP J24185152 23- B f2
R 1282 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1283 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A G1
R 1284 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A2
R 1285 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1286 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1287 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- B a1
R 1290 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- B b2
R 1292 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-10 B b2
R 1292 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 11- B b2
R 1293 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b2
R 1294 CHIP RES. 2.7 1/10W 5% RMC1/10T 2R7J J24205279 1- B g2
R 1295 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A F3
R 1296 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-22 B f2
R 1296 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 23- B f2
R 1298 CHIP RES. 4.7 1W 5% RMC1 4R7JTE J24305479 1- B g3
R 1299 CHIP RES. 4.7 1W 5% RMC1 4R7JTE J24305479 1- B g3
R 1300 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B a2
R 1301 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A G2
R 1302 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A G2
R 1303 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A G2
R 1304 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b2
R 1305 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A F3
R 1306 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A F3
R 1307 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A B4
R 1308 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B f2
R 1309 CHIP RES. 270 1/10W 5% RMC1/10T 271J J24205271 1- B g2
R 1310 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A F3
R 1311 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B f2
R 1312 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b2
R 1313 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B f2
R 1317 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b2
R 1319 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A B4
R 1320 CHIP RES. 1 1/10W 5% RMC1/10T 1R0J J24205010 1- B g2
R 1324 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A E2
R 1325 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A E2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
