Vertex Standard VXR-9000 Service Manual

H-28
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
R 1326 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A F2
R 1327 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1328 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1329 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1330 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 1331 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A F3
R 1332 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A F2
R 1333 CHIP RES. 0 1W 5% RMC1 JPATE J24305000 1- A A4
R 1334 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B3
R 1336 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B b1
R 1337 CHIP RES. 2.2k 1/16W 1% RMC1/16 222FTP J24183222 1- A B3
R 1338 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B e4
R 1339 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f3
R 1340 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e3
R 1341 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-2
R 1342 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-2
R 1343 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f3
R 1344 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f3
R 1345 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A C4
R 1346 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A C4
R 1347 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A C4
R 1348 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f3
R 1350 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-2
R 1351 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1-20 A C3
R 1351 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 VER. A 21-87 A C3
R 1351 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 VER. A 88- A C3
R 1351 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 VER. D 21- A C3
R 1352 CARBON FILM RES. 2.2k 1/6W 5% RD16PJ222 2.2K J01225222 3-22 A D3
R 1352 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 VER. A 23-24 A D3
R 1352 CARBON FILM RES. 2.2k 1/6W 5% RD16PJ222 2.2K J01225222 VER. D 23-24 A D3
R 1352 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 25- A D3
R 1353 CARBON FILM RES. 22k 1/6W 5% RD16PJ223 22K J01225223 11-22 A B4
R 1353 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 VER. A 23-24 A B4
R 1353 CARBON FILM RES. 22k 1/6W 5% RD16PJ223 22K J01225223 VER. D 23-24 A B4
R 1353 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 25- A B4
R 1354 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 VER. A 23- A C1
R 1501 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 3-15 B c1
R 1501 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 16-22 B c1
R 1501 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 23- B c1
R 1502 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 3-15 B d1
R 1502 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 16-22 B d1
R 1502 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 23- B d1
R 1503 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23-24 B c3
R 1503 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 25-98 B c3
R 1503 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 99- B c3
R 1504 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23-24 B c2
R 1504 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 25- B c2
R 1505 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23-24 B c2
R 1505 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 25- B c2
R 1507 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 3- B c2
R 1508 CHIP RES. 180 1/16W 5% RMC1/16 181JATP J24185181 3-15 B d2
R 1508 CHIP RES. 180 1/16W 5% RMC1/16 181JATP J24185181 16-22 B d2
R 1508 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 VER. A 23-24 B d2
R 1508 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 25- B d2
R 1509 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 3- B c2
R 1512 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 3- B c1
R 1513 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 3-15 B c2
R 1513 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 16-22 B c2
R 1513 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 VER. A 23-24 B c2
R 1513 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 25- B c2
R 1514 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 VER. A 23-24 B c2
R 1514 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 25- B c2
R 1515 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 3-15 B c1
R 1515 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 16-22 B c1
R 1515 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 VER. A 23-24 B c1
R 1515 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 25- B c1
R 1516 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23-24 B c1
R 1516 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 25- B c1
R 1517 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23-24 B c1
R 1517 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 25- B c1
R 1518 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 VER. A 23-24 B c1
R 1518 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 25-98 B c1
R 1518 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 99- B c1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
