Vertex Standard VXR-9000 Service Manual

H-29
MAIN Unit
Parts List
VXR-9000 UHF Service Manual
R 1519 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 3-15
R 1519 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 16-22
R 1519 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 VER. D 23-24
R 1520 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 3-15
R 1520 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 16-22
R 1520 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 VER. D 23-24
R 1521 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 3-
R 1521 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 16-22
R 1521 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 VER. D 23-24
T 1001 COIL WIDE-TRANS. 3-317611 L0022478 1- A E4
T 1002 COIL WIDE-TRANS. 050812563 92H5 L0022479 1- A E3
T 1003 COIL WIDE-TRANS. 3-317611 L0022478 1- A E3
TC1001 TRIMMER CAP. 10pF TC13C100C-TP03 K91000255 1- A G3
TC1002 TRIMMER CAP. 10pF TC13C100C-TP03 K91000255 1- A G3
TH1001 THERMISTOR 157-502-53002TP G9090049 1- A D4
TH1002 THERMISTOR NTCG203SH223JT G9090106 1- A C3
TH1003 THERMISTOR 157-502-53002TP G9090049 1- A B4
TH1004 THERMISTOR 157-501-53009TP G9090058 1- A C1
TP1001 TERMINAL TP-K IPS-1136 Q5000050 1- A D2
TP1003 TERMINAL TP-K IPS-1136 Q5000050 1- A F1
X 1001 XTAL OSC 14.4MHz TTS12V 14.4MHZ H9500650 1- A C3
X 1002 XTAL TSS-6035B 72.895MHz 72.895MHZ H0103290 1- A E1
X 1003 XTAL OSC 14.4MHz TTS12V 14.4MHZ H9500650 1- A G1
XF1001 XTAL FILTER TM7050A MF73P H1102363 1-6 A D2
XF1001 XTAL FILTER TM7050A MF73P2 H1102381 7- A D2
XF1002 XTAL FILTER TM7050A MF73P H1102363 1- A D1
XF1501 XTAL FILTER TM7050A MF73P H1102363 3-15 B c2
XF1501 XTAL FILTER TM7050A MF73P H1102363 16-22 B c2
XF1501 XTAL FILTER MFT73M 73.35MHZ H1102391 VER. A 23-24 B c2
XF1501 XTAL FILTER MFT73M 73.35MHZ H1102391 25- B c2
XF1502 XTAL FILTER TM7050A MF73P H1102363 3-15 B c1
XF1502 XTAL FILTER TM7050A MF73P H1102363 16-22 B c1
XF1502 XTAL FILTER MFT73M 73.35MHZ H1102391 VER. A 23-24 B c1
XF1502 XTAL FILTER MFT73M 73.35MHZ H1102391 25- B c1
SHIELD CASE CASE-S7GDH L9190016 1-5
SHIELD CASE RA0014200 1-
SHIELD CASE VCO R0151950 1-
SHIELD CASE (A) RA0073900 1-
SHIELD CASE (A) RA0073900 1-
SHIELD CASE RA0498300 1-
SHIELD CASE RA0014300 1-
SHIELD CASE (MIXER) RA0439400 1-
LEAF SPRING R0140031 VER. A 23-
LEAF SPRING R0140031 VER. D 23-
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
