K-9

PA Unit (Lot. 1~20)

Parts List

VXR-9000 UHF Service Manual

PCB with Components CS1813001

C 5001 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 5002 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A4

C 5003 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 1- A B4

C 5004 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A B5

C 5005 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 5006 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A4

C 5007 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A A3

C 5007 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A A3

C 5008 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 5009 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A4

C 5010 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 5011 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B4

C 5012 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A3

C 5013 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A4

C 5014 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A A2

C 5014 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A A2

C 5015 CHIP CAP. 0.22uF 16V B GRM219B11C224KC01D K22120806 1-2 A B4

C 5015 CHIP CAP. 0.22uF 10V B GRM188B11A224KA01D K22104801 3- A B4

C 5016 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 5017 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B4

C 5018 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A B5

C 5019 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A B3

C 5020 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B5

C 5021 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A C4

C 5021 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A C4

C 5022 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B4

C 5023 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C4

C 5025 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B3

C 5026 CHIP CAP. 82pF 50V CH GRM1882C1H820JA01D K22174233 1- A B3

C 5027 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B5

C 5028 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B5

C 5029 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A B5

C 5031 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A B4

C 5031 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A B4

C 5032 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B2

C 5033 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C2

C 5034 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C2

C 5035 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 1- A C3

C 5037 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A C2

C 5037 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A C2

C 5038 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A C3

C 5039 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C1

C 5040 AL.ELECTRO.CAP. 470uF 35V RE2-35V471MH5# K40169026 1- A C2

C 5041 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A E3

C 5042 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A D3

C 5043 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C5

C 5044 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A D2

C 5045 CHIP CAP. 0.01uF 50V B ECUV1H103KBG K22179562 1- A C5

C 5046 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A D2

C 5046 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A D2

C 5047 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A D5

C 5047 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A D5

C 5048 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D1

C 5049 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D5

C 5050 CHIP CAP. 82pF 50V CH GRM1882C1H820JA01D K22174233 1- A E3

C 5051 CHIP CAP. 82pF 50V CH GRM1882C1H820JA01D K22174233 1- A E3

C 5054 FILM CAP. 18pF 500V UC232H0180J-T K33279029 1- A F2

C 5055 FILM CAP. 33pF 500V UC232H0330J-T K33279024 1- A F2

C 5056 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A F4

C 5057 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A E1

C 5058 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A F1

C 5059 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A F1

C 5059 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A F1

C 5060 CHIP CAP. 0.001uF 50V B ECUV1H102KBN K22179550 1-99 A E1

C 5060 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 100- A E1

C 5061 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A H3

C 5062 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A D2

C 5063 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A G1

C 5064 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A G3

C 5065 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A G5

C 5066 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G5

C 5067 FILM CAP. 120pF 500V UC342H1200J-T K33279026 1- A F5

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
