VX-2100/-2200
(
VHF
)
Service Manual 6
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERSION SIDE LAY ADR
PCB with Components
MAIN UNIT (w/o Q1009 PA Module) CS2124701 50 W
CS2124702 25 W
FRONT-A UNIT (VX-2100) CB3472001
FRONT-B UNIT (VX-2200) CB3473001
Mechanical Parts
FRONT PANEL ASSY RA079170A VX-2100
FRONT PANEL ASSY RA079160A VX-2200
CHASSIS RA079000F
TOP CASE RA0790200
RUBBER PACKING RA080360A
SHIELD CASE RA0790300
RUBBER KNOB RA0845300
VOL KNOB ASSY RA1433500
LIGHT GUIDE RA0787600 VX-2100
HOLDER RA078750A VX-2100
MYLAR SHEET RA1062100 VX-2100
LED FILTER RA0997300 VX-2100
LCD HOLDER RA0786300 VX-2200
LIGHT GUIDE RA078640A VX-2200
REFLECTOR SHEET RA0790900 VX-2200
SPONGE RUBBER RA0786900 VX-2200
INTER CONNECTOR RA0786200 VX-2200
Electrical Parts
SPEAKER 18-ohm M4090226
CONNECTOR P1091172 ANTENNA
CONNECTOR P1090654A EXT SP
WIRE ASSY T9207044B DC POWER CABLE
WIRE ASSY T9207582 FLAT CABLE
MAIN UNIT Electrical Parts
CD1001 CERAMIC DISC JTBC450C7 H7901500 B b5
CF1001 CERAMIC FILTER LTM450EW-A H3900574A A J4
CF1002 CERAMIC FILTER LTM450GW-A H3900573A A J4
F 1001 CHIP FUSE 1.25A FCC16 132ABTP Q0000109 A B2
Q 1009 IC RA60H1317M1A-201 G1094957 50 W A D1
Q 1009 IC RA30H1317M1-201 G1094958 25 W A D1
VR1001 POT. R9710NS-FB15A7.0-A203-005 J60800325 A A5
X 1001 XTAL HC-49SMD 11.0592MHz FYSMD110592 H0103318 A A4
X 1002 TCXO 16.8MHz TTS14VSB-A3 16.80MHZ H9501100 A G4
X 1003 XTAL U3B 4.194304MHz 4.194304MHZ H0103284 B g5
XF1001 XTAL FILTER MFT67P 67.650MHZ H1102471 A H4
FRONT-A UNIT
(
VX-2100
)
Electrical Parts
DS2001 LED ELS-512SURWA/S530-A3 G2090796 A D1
FRONT-B UNIT
(
VX-2200
)
Electrical Parts
DS3001 LCD TP5434 (AC061) G6090173 A C1

Vertex VX-2100 series Specifications

General

Voltage	13.6 V DC ± 15%
Channel Spacing	12.5 / 25 kHz
Output Power	5 W
Frequency Range	VHF: 134-174 MHz, UHF: 400-470 MHz
Weight	1.2 kg
