Vertex VX-6R User Manual

25
CNTL Unit
R 3053 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B a4
R 3054 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a4
R 3055 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B a4
R 3056 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c4
R 3057 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c4
R 3058 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b4
R 3059 CHIP RES. 270k 1/16W 0.5% MCR01MZPD2703 J24189329 1- B a4
R 3060 CHIP RES. 390k 1/16W 0.5% MCR01MZPD3903 J24189331 1- B c4
R 3061 CHIP RES. 470k 1/16W 0.5% MCR01MZPD4703 J24189332 1- B c4
R 3062 CHIP RES. 330k 1/16W 0.5% MCR01MZPD3303 J24189330 1- B c4
R 3063 CHIP RES. 270k 1/16W 0.5% MCR01MZPD2703 J24189329 1- B b4
R 3064 CHIP RES. 100k 1/16W 0.5% MCR01MZPD1003 J24189386 1- B a4
R 3065 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a2
R 3066 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B a2
R 3067 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a1
R 3068 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a1
R 3069 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 3070 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B a2
R 3071 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a4
R 3072 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a4
R 3073 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a4
R 3074 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B a4
R 3075 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B b1
R 3076 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 3077 CHIP RES. 330k 1/16W 0.5% MCR01MZPD3303 J24189330 1- B c4
R 3078 CHIP RES. 330k 1/16W 0.5% MCR01MZPD3303 J24189330 1- B c4
R 3079 CHIP RES. 220k 1/16W 0.5% MCR01MZPD2203 J24189389 1- B c4
R 3080 CHIP RES. 470k 1/16W 0.5% MCR01MZPD4703 J24189332 1- B c4
R 3081 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c4
R 3082 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b4
R 3083 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 3084 CHIP RES. 1M 1/16W 1% MCR01MZSF1004 J24189333 1- B b4
R 3085 CHIP RES. 3.3M 1/16W 5% RMC1/16S 335JTH J24189324 1- B b4
R 3086 CHIP RES. 150k 1/16W 0.5% MCR01MZPD1503 J24189328 1- B b4
R 3087 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 3088 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 3089 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 3090 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a4
R 3091 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a4
R 3092 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a4
R 3093 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b2
R 3094 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B c1
R 3095 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B c2
R 3096 CHIP RES. 4.7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- B b4
R 3097 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A3
R 3098 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a4
R 3099 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B a4
R 3100 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B a4
R 3101 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c1
R 3102 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c1
R 3103 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A3
R 3104 CHIP RES. 2.2 1/16W 5% RMC1/16 2R2JATP J24185229 1- B b4
R 3105 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B2
R 3106 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B b1
R 3107 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B c1
R 3108 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B c1
R 3109 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c1
R 3110 CHIP RES. 390k 1/16W 0.5% MCR01MZPD3903 J24189331 1- B a1
R 3111 CHIP RES. 10k 1/16W 0.5% MCR01MZPD1002 J24189374 1- B a1
R 3112 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 3113 CHIP RES. 68k 1/16W 0.5% MCR01MZPD6802 J24189384 1- B a1
R 3114 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
