26
CNTL Unit
R 3115 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 3116 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A A2
R 3117 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B2
R 3118 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
R 3119 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
R 3120 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A1
R 3121 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 3122 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B1
R 3123 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B1
R 3124 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A1
R 3125 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A1
R 3126 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B a1
R 3127 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B c3
R 3128 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 3129 CHIP RES. 4.7 1/2W 5% RMC1/2 4R7JCTP J24275479 1- B c2
R 3130 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c1
R 3131 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c1
R 3132 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 3133 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b3
R 3134 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b3
R 3135 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B c2
R 3136 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b2
R 3137 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b2
R 3138 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b2
R 3139 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B2
R 3140 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c3
R 3141 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b1
RB3001 BLOCK RES. MNR04M0ABJ102 J42900039 1- A A2
RB3002 BLOCK RES. MNR04M0ABJ102 J42900039 1- A A2
RB3003 BLOCK RES. MNR04M0ABJ102 J42900039 1- A B2
RB3004 BLOCK RES. MNR04M0ABJ102 J42900039 1- A B2
RB3005 BLOCK RES. MNR04M0ABJ102 J42900039 1- A B1
RB3006 BLOCK RES. MNR04M0ABJ102 J42900039 1- A B1
RB3007 BLOCK RES. MNR04M0ABJ102 J42900039 1- A A1
RB3008 BLOCK RES. MNR04M0ABJ102 J42900039 1- A A1
RB3009 BLOCK RES. MNR04M0ABJ102 J42900039 1- A A1
TH3001 THERMISTOR ERTJ1VV473J G9090122 1- A B2
X 3001 XTAL VT-200 32.768KHZ 20PPM/6PF H0103267 1- A A2
X 3002 XTAL XPFEGC 3.579545MHz 3.579545MHZ H0103304 1- B a1
LIGHT GUIDE (LCD) RA0646600 1-
REFLECTOR SHEET RA0646700 1-
INTER CONNECTOR RA0646800 1-
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
