Vertex VX-6R User Manual

33
AF Unit
D 2011 DIODE 1SS400G T2R G2070934 3- B b1
FB2001 CHIP COIL BLM10A121SPT L1690843 1- A A1
FB2002 CHIP COIL BLM10A121SPT L1690843 1- A B1
FB2003 CHIP COIL BLM10A121SPT L1690843 1- A B1
FB2004 CHIP COIL BLM10A121SPT L1690843 1- A B1
FB2005 CHIP COIL BLM10A121SPT L1690843 1- A B1
J 2001 CONNECTOR HSJ1594-010055 P1090896 1- B b1
J 2002 CONNECTOR 9637S-26-Y905 P1091227 1- A A2
L 2001 M.RFC 0.39uH 2% C1608CB-R39G L1691107 1- B c2
L 2002 M.RFC 0.15uH 2% C1608CB-R15G L1691101 1- B c2
L 2003 M.RFC 0.33uH 2% C1608CB-R33G L1691106 1- B b2
L 2004 M.RFC 0.22uH LK1608 R22K-T L1690410 1- B c1
L 2005 M.RFC 0.47uH LK1608 R47K-T L1690414 1- B c1
L 2006 M.RFC 1uH LK1608 1R0K-T L1690687 1- B c1
L 2007 M.RFC 0.33uH 2% C1608CB-R33G L1691106 1- B b2
L 2008 M.RFC 0.22uH LK1608 R22K-T L1690410 1- B b1
L 2009 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- B b1
L 2010 M.RFC 10uH 2% KQ1008TE100G L1691216 1- A B2
L 2011 M.RFC 0.47uH LK1608 R47K-T L1690414 3- B c2
Q 2001 TRANSISTOR DTC144EE TL G3070075 1- B c2
Q 2002 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c2
Q 2003 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 2004 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c1
Q 2005 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B b2
Q 2006 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B b2
Q 2007 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c1
Q 2008 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c1
Q 2009 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B b1
Q 2010 IC TA31136FN(EL) G1091605 1- B a2
Q 2011 TRANSISTOR 2SA1774 TL R G3117748R 1- A A1
Q 2012 TRANSISTOR 2SC4617 TL R G3346178R 1- A A1
Q 2013 TRANSISTOR 2SA1774 TL R G3117748R 1- A C2
Q 2014 TRANSISTOR 2SA1774 TL R G3117748R 1- A B2
Q 2015 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 2016 TRANSISTOR 2SA1774 TL R G3117748R 1- A A1
Q 2017 TRANSISTOR 2SC4617 TL R G3346178R 1- A B2
Q 2018 TRANSISTOR DTC144EE TL G3070075 1- B a2
Q 2019 FET 2SJ364-R(TX) G3703648R 1- B a2
Q 2020 TRANSISTOR 2SC4617 TL R G3346178R 1- A B1
Q 2021 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 2022 TRANSISTOR 2SC4617 TL R G3346178R 1- B a2
Q 2023 TRANSISTOR FMMTL718TA G3070335 1- B a1
Q 2023 TRANSISTOR CPH6102-TL G3070223 3- B a1
Q 2024 TRANSISTOR DTA144EE TL G3070074 1- B b1
Q 2025 TRANSISTOR DTC144EE TL G3070075 1- B b1
Q 2026 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 2027 FET 2SJ364-R(TX) G3703648R 1- B a2
Q 2028 IC TDA7233D-TR G1091112 1- A B1
Q 2029 TRANSISTOR DTC123YE TL G3070095 1- B b1
Q 2030 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 2031 TRANSISTOR 2SC4617 TL R G3346178R 1- A C1
Q 2032 TRANSISTOR 2SA1774 TL R G3117748R 1- A C1
Q 2033 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 2034 TRANSISTOR 2SC4617 TL R G3346178R 1- A C1
Q 2035 TRANSISTOR EMD2 T2R G3070312 1- A B1
R 2002 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b2
R 2003 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c2
R 2004 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c1
R 2005 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c2
R 2006 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 2007 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c1
R 2008 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B b2
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
