Vertex VX-6R User Manual

34
AF Unit
R 2009 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 2010 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2011 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b2
R 2013 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B b2
R 2014 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c1
R 2016 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c1
R 2017 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c1
R 2018 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c1
R 2020 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b2
R 2021 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 2022 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B b2
R 2023 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B b1
R 2025 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 2026 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b1
R 2027 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B b2
R 2028 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 2029 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a2
R 2030 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b1
R 2031 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a1
R 2032 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a1
R 2033 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 2034 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 2035 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 2036 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 2037 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- A C2
R 2038 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A B2
R 2039 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B2
R 2040 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 2041 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B a2
R 2042 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a2
R 2043 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a2
R 2044 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B a2
R 2045 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B a2
R 2046 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 2047 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- B a1
R 2048 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B a1
R 2049 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a1
R 2050 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 2051 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 2052 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a2
R 2053 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 2054 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A B1
R 2055 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A B2
R 2056 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A B2
R 2057 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2058 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A B1
R 2059 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B a1
R 2060 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a1
R 2061 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a1
R 2062 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 2063 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B a1
R 2064 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 2065 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b1
R 2066 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b1
R 2067 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a2
R 2068 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B a2
R 2069 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a2
R 2070 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 2071 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 2072 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a2
R 2073 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 2074 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
