VCO Unit
*** VCO UNIT ***
PCB with Components CB3028001
Printed Circuit Board FR007830D 1-
C 4001 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4002 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4003 CHIP CAP. 0.5pF 50V CK UMK105CK0R5CW-F K22178247 1- A A1
C 4004 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4005 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4006 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A1
C 4007 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4008 CHIP CAP. 6pF 50V CH GRM36CH060B50PT K22178293 1- A A1
C 4009 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A A1
C 4010 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- A A1
C 4011 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4012 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- A A1
C 4013 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4014 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4015 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A A1
C 4017 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A A1
C 4018 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4019 CHIP CAP. 56pF 50V CH UMK105CH560JW-F K22178276 1- A A1
C 4020 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4021 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4022 CHIP CAP. 39pF 50V CH UMK105CH390JW-F K22178272 1- A A1
C 4023 CHIP CAP. 62pF 50V CH UMK105CH620JW-F K22178277 1- A A1
C 4024 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- A A1
C 4025 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4026 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4027 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4028 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A A1
C 4029 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A1
C 4030 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A A1
C 4031 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- A A1
C 4032 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4033 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- A A1
C 4034 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4035 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B1
C 4036 CHIP CAP. 47pF 50V CH UMK105CH470JW-F K22178274 1- A A1
C 4037 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A A1
C 4038 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- A A1
C 4039 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4040 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4041 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A A1
C 4042 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4043 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A B1
C 4044 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4045 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4047 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4048 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A1
C 4049 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A A1
D 4001 DIODE HVC355B(TAPE) G2070588 1- A A1
D 4002 DIODE HSC277TRF G2070584 1- A A1
D 4003 DIODE HSC277TRF G2070584 1- A A1
D 4004 DIODE 1SV325(TPH3) G2070848 1- A A1
D 4005 DIODE HSC277TRF G2070584 1- A A1
D 4006 DIODE HSC277TRF G2070584 1- A A1
D 4007 DIODE 1SV325(TPH3) G2070848 1- A A1
D 4008 DIODE 1SV325(TPH3) G2070848 1- A A1
D 4009 DIODE HSC277TRF G2070584 1- A A1
D 4010 DIODE 1SS400 TE61 G2070634 1- A A1
D 4011 DIODE 1SS400 TE61 G2070634 1- A A1
D 4012 DIODE 1SS400 TE61 G2070634 1- A A1
Parts List
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
