Vertex VX-6R - Page 55

55
VCO Unit
D 4013 DIODE 1SV325(TPH3) G2070848 1- A A1
D 4014 DIODE HSC277TRF G2070584 1- A A1
D 4015 DIODE 1SV325(TPH3) G2070848 1- A A1
J 4001 CONNECTOR AXK5F10335YP P1091136 1- B b1
J 4002 CONNECTOR AXK5F10335YP P1091136 1- B a1
L 4001 M.RFC 1uH LK1608 1R0K-T L1690687 1- A A1
L 4002 M.RFC 0.0068uH 5% C1608CB-6N8J L1691093 1- A A1
L 4003 M.RFC 0.0082uH 2% C1608CB-8N2G L1691226 1- A A1
L 4004 M.RFC 1uH LK1608 1R0K-T L1690687 1- A A1
L 4005 M.RFC 2.2uH LK1608 2R2K-T L1690634 1- A A1
L 4006 M.RFC 0.015uH 2% C1608CB-15NG L1691034 1- A A1
L 4007 M.RFC 0.024uH 2% C1608CB-24NG L1691281 1- A A1
L 4008 M.RFC 1uH LK1608 1R0K-T L1690687 1- A A1
L 4009 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A A1
L 4010 M.RFC 0.1uH 2% C1608CB-R10G L1691045 1- A A1
L 4011 M.RFC 1uH LK1608 1R0K-T L1690687 1- A A1
L 4012 M.RFC 0.33uH LK1608 R33K-T L1690412 1- A A1
L 4013 M.RFC 0.033uH HK1608 33NJ-T L1690522 1- A A1
L 4014 M.RFC 0.1uH LK1608 R10K-T L1690407 1- A B1
L 4015 M.RFC 0.22uH 2% C1608CB-R22G L1691103 1- A A1
Q 4001 TRANSISTOR DTC143ZE TL G3070102 1- A A1
Q 4002 TRANSISTOR EC3H07B-TL G3070286 1- A A1
Q 4003 TRANSISTOR DTC143ZE TL G3070102 1- A A1
Q 4004 TRANSISTOR EC3H07B-TL G3070286 1- A A1
Q 4005 TRANSISTOR EC3H07B-TL G3070286 1- A A1
Q 4006 TRANSISTOR EC3H07B-TL G3070286 1- A A1
Q 4007 TRANSISTOR DTC143ZE TL G3070102 1- A A1
R 4001 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 4002 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
R 4003 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A A1
R 4004 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A1
R 4005 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A A1
R 4006 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A1
R 4007 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A A1
R 4008 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 4009 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
R 4010 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A A1
R 4011 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A1
R 4012 CHIP RES. 68 1/16W 5% RMC1/16S 680JTH J24189011 1- A A1
R 4013 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 4014 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 4015 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 4016 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
R 4017 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A1
R 4018 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 4019 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A A1
R 4020 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 4021 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- A A1
R 4022 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A B1
R 4023 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- A A1
R 4024 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 4025 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B1
R 4026 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A1
R 4027 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
SHIELD CASE VCO RA0400300 1-
SHIELD SHEET RA043430B 1-
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
