3.2 Basic Settings
When the system is put into service for the first time, the parameters of controller module must be set based on the
actual system configuration, such as battery number, capacity, user’s charge current limit and other functional
requirements. Only after that can the controller module display system operation information and control the output.
(M221S,M222S controller password is 2; M225S controller password is1 )
OK
Comments
The system model has been set correctly in factory before delivery, check that the setting agrees with the
actual system.
(The path to check and set of the M221S\M222S controller：SettingsBat. SettingsBasic Settings）
NetSure 731 A41-S1：48V/SET；battery shunt coefficient：300A/25mV；
(The path to check and set of the M225Scontroller：Settings Shunt A）
NetSure 731 A41-S2：battery shunt coefficient：300A/25mV

Setting controller according to number of battery groups connected. Default: two groups.
(The path to check and set of the M221S\M222S controller：SettingsBat. SettingsBasic Settings
Bat.Fuse）
（No such settings for M225S controller）

Setting controller according to the capacity of battery groups connected. Default: 300Ah
（The path to check and set of the M221S\M222S controller：SettingsBat. SettingsBasic Settings
Capacity）
（The path to check and set of the M225S controller：Settings Capacity）

Setting LVD1: default:44V（If the subrack system is used for outdoor, default setting:46.6V）
（The path to check and set of the M221S\M222S controller：SettingsBat. SettingsLVD Settings
LVD1 Volt）
（The path to check and set of the M225Scontroller：SettingsLVD1，default setting:Yes
Relay 2 settings“SettingsRelay 2”,default setting “LVD1”）
Setting LVD2: default:43.2V（If the subrack system is used for outdoor, default setting:45.6V）
（The path to check and set of the M221S\M222S controller：SettingsBat. SettingsLVD Settings
LVD2 Volt
（The path to check and set of the M225Scontroller：SettingsLVD2，）
Setting AC input type. Default value: 1-PH
（The path to check and set of the M221S\M222S controller：SettingsInput SettingsAC PH）
（No such settings for M225S controller）
Walk-in T setting: default：8S
（The path to check and set of the M221S\M222S controller：SettingsRect SettingsWalk-in on，
default“Y”
(SettingsRect SettingsWalk-in T，default“8S”）
（The path to check and set of the M225Scontroller：Settings Walk-in T，default“8S“）
Setting controller according to the battery factory.Temperature compensation range:0～500mV/℃. Default：
72mV/℃.
（The path to check and set of the M221S\M222S controller：SettingsBat.settingsTemp.Comp）
（No such settings for M225S controller）

Set the charge current limit according to your needs. Setting range: 0.1 C10～0.25C10。Default：0.1C10
（The path to check and set of the M221S\M222S controller：Settings Bat. SettingsCharge）
（No such settings for M225S controller）

Set the controller according to the voltage suggested by the battery supplier.
Float charge voltage：42V～Boost charge(BC)，default：53.5V(If the subrack system is used for outdoor,
default voltage:54V)；
Boost chare voltage：Float charge(FC)～58V，default：56.4V
（The path to check and set of the M221S\M222S controller：Settings Bat. SettingsCharge）
（The path to check and set of the M225Scontroller：SettingsFloat/Boost）
SettingsFloat/Boost

Set the boost charge voltage higher 0.1V than float charge voltage for the free boost charge battery.
Close the battery MCBs and connect the battery.

