Example 2
Both monitor configurations in example two enable you to switch between display 1 on the left and display
2 on the right. Using the mouse cursor to switch from display 1 to display 2 also switches you from
computer 1 to computer 2.
Figure 2.17 Example 2 Physical Layout
Example 3
Example 3 depicts a multiple monitor configuration with the monitors connected at the corners. Example
3A is an invalid configuration because display 1 and display 2 do not share an overlapping area where the
mouse cursor can cross. Example 3B is valid since the two monitors overlap to create an area where the
mouse cursor can cross.
