30 HMX1080/HMX2080 User Manual
HMX TX&RX
Chapter 4 Specification
4.1 HMX1080 Specification
Table 4-1 HMX1080 Specification
Model No.
HMX1080T
HMX1080R
Component Type
Transmitter
Receiver
Connector
USB Port (Type B) x 2
USB Port (keyboard and mouse, Type A) x 2
DVI-I In Port x 1
USB Port ( Devices. Type A) x 2
DVI-I Out Port x 1
DVI-I Out Port x 1
IR Out Jack x 1
IR In Jack x 1
Mic.Jack x 2
Mic.Jack x 1
Speaker Jack x 2
Speaker Jack x 1
RJ45 connector x 2
RJ45 connector x 2
RS-232 Female x 1
RS-232 male x 1
Power Jack x 1
Power Jack x 1
Button
Functional button x 2
Functional button x 2
LED indicator
Red x 1
Red x 1
Green x 1
Green x 1
Yellow x 1
Dimension (L x W x H)
222 x 105 x 44 mm
222 x 105 x 44 mm
Weight
670g
660g
Resolution
1920 x 1200@60Hz
Power Adapter
DC 5V
Operation Temperature
0 ~ 40°C
Storage Temperature
-20 ~ 60°C
Humidity
0~90% RH, Non-condensing
Housing
Metal enclosure
Safety / Emission
CE, FCC
