Chapter 7 Operation
1) Power the transmitter, receivers and all the connected devices to on.
2) Long press the SELECT button on the front panel of transmitter or receiver to connect.
For more details, refer to the description of 7.1 Front panel buttons.
Note: Although this Virtual Matrix KVM over IP allows multiple concurrent users to access multiple computers at the
same time, the contentions may be happened if more than one user accesses the same computer. To avoid the
contentions, the authorization is designed and provided for the user who first accesses the computer. It may take a
few seconds if requires to access by other users.
7.1 Front panel buttons
These buttons provide a simple and intuitional operation for users. It’s easy to configure the transmitter/ receiver by
pressing the button directly.
7.1.1 Select/ Mode (Left/ Right) buttons
1) Long press the Select button and then power on. Long press to switch on and off the remote console.
2) Long press the Select button after turning off the power and then plug in the power adapter to power on, it will
see the Green/Red LEDs flash at the same time, then power off and on again. That will make the Receiver or
Transmitter set to factory default.
3) Long press the Mode button to connect online USB device
4) Long press the Mode button after offline, when the LED lit steady on, and then set the Jumbo Frame enabled (8000
Jumbo Frame).
Short press the Mode button after offline, when the LED lit flashing, and then set the Jumbo Frame enabled (1500
Jumbo Frame).
7.1.2 Keyboard Hotkeys
To select different PC from console, the keyboard hotkey is provided. Each keyboard hotkey sequence consists of
three specific keystrokes at least.
Hotkey sequence = SCROLL LOCK + SCROLL LOCK + Command key(s)
For detailed hotkey sequences and their corresponding functional commands, refer to the table below.
In addition, you can also define a desired hotkey instead of Scroll Lock if this key has been used in another program.
User-definable = Scroll Lock, Num Lock, Caps or L/R_Ctrl
Table 7-1 Keyboard hotkeys
