35 HMX1080/HMX2080 User Manual
HMX TX&RX
Table 5-2 Description 2
No.
Item
Description
1
Reset
Reset the unit.
2
Power indicator
Lights when power is on.
3
Link indicator
Lights when the connection between transmitter and receiver is active.
4
Select button
Press to connect or disconnect between the transmitter and receiver.
5
Mode button
Press to select Graphic mode or Video mode.
6
Mic. input jack
Connect to a microphone.
7
Audio output jack
Connect to a speaker.
8
Power jack
Connect to the power adapter.
9
LAN port 1
Connect to the LAN port of Tx, Rx or a Gigabit Ethernet Hub/Switch*.
10
LAN port 2
Connect to the LAN port of Tx, Rx or a Gigabit Ethernet Hub/Switch*.
11
Audio input jack
Connect to the audio output jack of PC.
12
Mic. output jack
Connect to the mic. input jack of PC.
13
IR output jack
Connect to the IR emitter.
14
USB Type-B connector
Connect to the host PC.
15
HID connector
Reserved.
16
RS-232 connector
Connect to the RS-232 port of PC.
17
DVI input connector 1
Connect to the DVI output of PC.
18
DVI output connector 1
Connect to a DVI monitor.
19
USB indicator
Lights when a USB peripheral is connected.
20
USB Type-A connector
Connect to a USB keyboard and mouse.
21
USB Type-A connector
Connect to USB peripherals.
22
IR input jack
Connect to the IR receiver.
23
RS-232 connector
Connect to a RS-232 device.
24
DVI input connector 2
Connect to the DVI output of PC.
25
DVI output connector 2
Connect to a DVI monitor.
Both LAN ports can be connected to the transmitter, receiver, Gigabit Ethernet Hub/Switch or a device can be
supported to connect to the Local Area Network using an RJ45 connector. Beware the connection may invalid if
connecting both LAN ports into a same hub/switch.
