Product Overview
Vertiv | Liebert CRD10 | User Manual 13
1.6.13 Ramp
Ramp is used to easily remove the unit from the pallet, the operation process illustration is shown in Figure
1-13.
Figure 1-13 Ramp Unloading
Remove the
fixing screws and
sheet metal
Place a slope
and connect it
with the pallet
Push the cabinet
slowly from the pallet
down to the ground
along the slope
