Available programs list for parameter 1:
Code
Description
Bypass /
No Output mode
AC
mode
ECO
mode
CVCF
mode
Battery
mode
Battery
Test
01
Output voltage
Y*
02
CVCF mode enable/disable
Y
03
Output frequency
Y
04
Acceptable low voltage for bypass
Y
05
Acceptable high voltage for bypass
Y
06
Acceptable low frequency for bypass
Y
07
Acceptable high frequency for bypass
Y
08
ECO mode enable/disable
Y
09
Acceptable low voltage for ECO mode
Y
10
Acceptable high voltage for ECO mode
Y
11
Acceptable low frequency for ECO
mode
Y
12
Acceptable high frequency for ECO
mode
Y
13
Phase auto adapt enable/disable**
Y
14
Bypass mode allowed/forbidden
Y
Y
15
Manual bypass enable/disable
Y
Y
16
Maximum battery discharge time setting
Y
Y
Y
Y
Y
Y
17
Reserved
Reserve for future options
18
Reserved
19
Reserved
20
Neutral loss detection
Y
Y
Y
Y
Y
Y
21
Battery voltage calibration
Y
Y
Y
Y
Y
Y
22
Charger voltage adjustment
Y
Y
Y
Y
Y
Y
23
L1 inverter voltage adjustment
Y
Y
Y
24
L2 inverter voltage adjustment
Y
Y
Y
25
L3 inverter voltage adjustment
Y
Y
Y
26
L1 output voltage calibration
Y
Y
Y
27
L2 output voltage calibration
Y
Y
Y
28
L3 output voltage calibration
Y
Y
Y
*Y means that this program can be set in this mode.
**This function allows UPS input phase sequence more flexible. If it is enabled, UPS can adapt several kinds of
phase difference even it works like a single phase UPS. If it is disabled, UPS only can work under standard
input phase sequence among L1, L2, and L3. Please refer to program 13 below for more details about this
setting.
Note: All parameter settings will be saved only when UPS shuts down normally with internal or external battery
connection. (Normal UPS shutdown means turning off input breaker in bypass or no output mode).
