Specifications80
Table 7-3 Power-distribution Specifications
MODEL NUMBER
PD5-CE6HDWRMBS
PD5-CE6HDWRMBSU
PD5-CE10HDWRMBS
PD5-CE10HDWRMBSU
Amp Rating 50 A 63 A
Input Power Connection Single-phase (L1-L2-G) hard-wired
Output Power Connection Single-phase (L1-L2-G) hard-wired
Includes
Two IEC320 C19 16A/250V Sockets
Six C13 10A/250V Sockets
Four IEC320 C19 16A/250V Sockets,
Four C13 10A/250V Sockets
Input Branch Circuit Breaker,
Supplied by User
50 A 70 A
Table 7-4 External Battery Specifications
MODEL NUMBER GXT5-EBC72VRT2U GXT5-EBC192VRT3U
USED W/UPS MODEL 3000 VA MODELS 5 – 10-KVA MODELS
Dimensions, D×W×H, in. (mm)
Unit (with bezel) 23�7 x 16�9 x 3�3 (602 × 430 × 85) 430 x 630 x 130 (16�9 x 24�8 x 5�1)
Shipping 24�3 x 22�4 x 10�3 (617 x 570 x 262) 840 x 670 x 465 (33 x 26�4 x 18�3)
Weight, lb.(Kg)
Unit 85�8 (39) 57�6 (127)
Shipping 110 (50) 80 (176�4)
Battery
Type Valve-regulated, non-spillable, lead acid
Qty × Voltage 6 × 12 V 16 x 12 V
Battery Mfr�/Part# LEOCH DJW12-9�0
Backup time See Battery Run Times on page 81
Environmental Requirements
Operating Temperature, °F (°C) 32 to 104 (0 to 40)
Storage Temperature, °F (°C) 5 to 104 (–15 to 40)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 3,000 m (9,842�5 ft�) at 25°C (77°F)
Agency
Safety
EN 62040-1:2008+A1:2013; GS mark;
UL 1778 5th Edition and CSA 22�2 No� 107�1
IEC62040-1:2008, GS mark;
UL1778, c-UL listed
Transportation ISTA Procedure 1A ISTA Procedure 1E
