Vertiv Liebert Mini-Mate2 MMD24E - Page 52

208/230 - 1 Ph - 60Hz 277 - 1 Ph - 60Hz 208/230 - 3 Ph - 60Hz 460 - 3 Ph - 60Hz
Base Evaporator
Model Number
MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E
Condensing Unit Model Number MC*24A MC*36A MC*24A MC*36A MC*24A MC*36A MC*24A MC*36A
WSA 57.8 65.5 48.8 53.7 — 44.5 — 22.0
OPD 60 70 50 60 — 50 — 25
with SCR Reheat
3
FLA 52.7 71.7 44.4 59.1 — 44.6 — 22.0
WSA 63.0 86.4 53.3 71.7 — 53.6 — 26.6
OPD 70 90 60 80 — 60 — 30
with Humidifier
FLA 29.9 36.4 24.8 28.7 — 26.9 — 13.3
WSA 32.9 40.7 27.4 32.3 — 29.9 — 14.9
OPD 40 50 35 45 — 40 — 20
with Electric Reheat and Humidifier
FLA 48.5 55.0 40.8 44.7 — 37.3 — 18.3
WSA 57.8 65.5 48.8 53.7 — 44.5 — 22.0
OPD 60 70 50 60 — 50 — 25
with SCR Reheat and Humidifier
3
FLA 59.1 78.1 50.1 64.8 — 51.0 — 25.4
WSA 69.4 92.8 59.0 77.4 — 60.0 — 30.0
OPD 70 100 60 80 — 70 — 35
* Specify disconnect or no disconnect
Notes:
1. Belt drive data includes externally mounted high static blower box, powered from evaporator unit.
2. Use MM*24E and MM*36E for MM*24K & MM*36K, respectively, except with SCR reheat.
3. SCR Reheat not available with MM*24K or MM*36K.
Table 9.8 Electrical data, 60Hz air-cooled systems using single-point power kit, evaporator with belt-
drive blowers and indoor condensing unit (continued)
220 - 1 Ph - 50Hz 380/415 - 3 Ph - 50Hz
Base Evaporator Model Number MM*35E MM*35E
Condensing Unit Model Number MC*35A MC*35A
Cooling Only
FLA 22.9 9.2
with Electric Reheat
Table 9.9 Electrical data, 50Hz air-cooled systems using
single-point power kit, evaporator with direct-drive
blowers and indoor condensing unit
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 52
