Vertiv NetSure 700NVBA - Page 32

Vertiv | +24 VDC Power System User Manual (Section 6013) | Rev. G
32
MCA
Menu
Tree
Line No.
(Section
6022)
Message Displayed
Associated
with...
Definition
Can this value
be changed?
92 SUBLOAD** #####A
Subsystem
Load Menu
Displays individual load current
through a subsystem shunt.
** = designation of the subsystem
load shunt.
#### = value.
No
93 MEASUREMENT MENU
Subsystem
Load Menu
Moves you back to this menu. No
94 NORMAL DISPLAY
Subsystem
Load Menu
Moves you to the beginning of the
MCA Menu Tree. "SYSTEM OK" or
"## ALARMS ACTIVE" is displayed.
No
94A
BAT** CHG #####A
or
BAT** DIS #####A
Battery
Load Menu
Displays individual charge or
discharge current through a battery
shunt.
** = designation of the battery shunt.
#### = value.
No
94B MEASUREMENT MENU
Battery
Load Menu
Moves you back to this menu. No
94C NORMAL DISPLAY
Battery
Load Menu
Moves you to the beginning of the
MCA Menu Tree. "SYSTEM OK" or
"## ALARMS ACTIVE" is displayed.
No
95 FLOAT = ###.##V
System
Adjustment
Menu
Displays float voltage set point.
Yes, see "MCA
System
Adjustments".
96 TEST/EQ = ###.##V
System
Adjustment
Menu
Displays test/equalize voltage set
point.
Yes, see "MCA
System
Adjustments".
97 SET HVS = ###.##V
System
Adjustment
Menu
Displays high voltage shutdown set
point.
Yes, see "MCA
System
Adjustments".
98 [Reserved] -- -- --
99
CURR LIM = ####A
or
CURRLIM = ####MAX
System
Adjustment
Menu
Displays system current limit set
point.
or
Displays sum of maximum
capabilities of all Rectifier Modules
(PCUs) installed.
Yes, see "MCA
System
Adjustments".
