Vertiv NetSure 700NVBA - Page 33

Vertiv | +24 VDC Power System User Manual (Section 6013) | Rev. G
33
MCA
Menu
Tree
Line No.
(Section
6022)
Message Displayed
Associated
with...
Definition
Can this value
be changed?
99A
BATTLIM DISABLED
or
BATTLIM = #####A
System
Adjustment
Menu
Indicates the battery recharge
current limit feature is disabled.
or
Displays battery recharge current
limit set point.
Yes, see "MCA
System
Adjustments".
100 100% CURR: ####A
System
Adjustment
Menu
This value is only displayed. MCA
calculates the value from all Rectifier
Modules (PCUs) installed. There is
no user adjustment.
No
101 ADJUSTMENT MENU
System
Adjustment
Menu
Moves you back to this menu. No
102 NORMAL DISPLAY
System
Adjustment
Menu
Moves you to the beginning of the
MCA Menu Tree. "SYSTEM OK" or
"## ALARMS ACTIVE" is displayed.
No
103
SYS HV1 = ###.##V
or
HI FLOAT = ###.##V
Alarm
Adjustment
Menu
Displays high voltage alarm 1 (high
float) alarm set point.
Yes, see "MCA
System
Adjustments".
104
SYS HV2 = ###.##V
or
HI VOLTAGE = ###.##V
Alarm
Adjustment
Menu
Displays high voltage alarm 2 (high
voltage) alarm set point.
Yes, see "MCA
System
Adjustments".
105
SYS BOD = ###.##V
or
LO FLOAT = ###.##V
Alarm
Adjustment
Menu
Displays battery on discharge (low
float) alarm set point.
Yes, see "MCA
System
Adjustments".
106
SYS 50% = ###.##V
or
VERYLOVOLT = ###.##V
or
LO VOLTAGE = ###.##V
Alarm
Adjustment
Menu
Displays 50% battery on discharge
(very low voltage) (low voltage)
alarm set point.
Yes, see "MCA
System
Adjustments".
107 SYSCURR = #####A
Alarm
Adjustment
Menu
Displays system current alarm set
point.
Yes, see "MCA
System
Adjustments".
108 SUB HV = ###.##V
Alarm
Adjustment
Menu
Displays subsystem high voltage
alarm set point.
Yes, see "MCA
System
Adjustments".
109 SUB LV = ###.##V
Alarm
Adjustment
Menu
Displays subsystem low voltage
alarm set point.
Yes, see "MCA
System
Adjustments".
