Vertiv NetSure 700NVBA - Page 34

Vertiv | +24 VDC Power System User Manual (Section 6013) | Rev. G
34
MCA
Menu
Tree
Line No.
(Section
6022)
Message Displayed
Associated
with...
Definition
Can this value
be changed?
110 SUBCURR = #####A
Alarm
Adjustment
Menu
Displays subsystem current alarm
set point.
Yes, see "MCA
System
Adjustments".
110A BAT CHG = #####A
Alarm
Adjustment
Menu
Displays battery recharge current
alarm set point.
Yes, see "MCA
System
Adjustments".
110B
HI TEMP ** = ###ºC
or
HI TEMP ** IS OFF
Alarm
Adjustment
Menu
Displays the high temperature alarm
set point or that this feature has
been disabled.
###ºC = current setting for the high
temperature alarm.
** = the designation of the
temperature probe.
Yes, see "MCA
System
Adjustments".
110C
LO TEMP ** = ###ºC
or
LO TEMP ** IS OFF
Alarm
Adjustment
Menu
Displays the low temperature alarm
set point or that this feature has
been disabled.
###ºC = current setting for the low
temperature alarm.
** = the designation of the
temperature probe.
Yes, see "MCA
System
Adjustments".
111
TEST ALM RELAYS
or
TESTING RELAY ##
or
Alarm(s) Active
Alarm
Adjustment
Menu
Activates the alarm relay test feature
or indicates this feature is currently
in progress.
or
The user tried to activate this feature
when alarm relays were in an alarm
state.
Yes, see
"System
Operating
Procedures".
112 ADJUSTMENT MENU
Alarm
Adjustment
Menu
Moves you back to this menu. No
113 NORMAL DISPLAY
Alarm
Adjustment
Menu
Moves you to the beginning of the
MCA Menu Tree. "SYSTEM OK" or
"## ALARMS ACTIVE" is displayed.
No
114 LVD ** = ##.#V
LVD
Adjustment
Menu
Displays low voltage disconnect
circuit disconnect set point.
** = the designation of the LVD
circuit (either 1A, 1B, 2A, 2B, 3A, or
3B).
Yes, see "MCA
System
Adjustments".
