List of Symbols
Warning. Pay special attention to procedures
and notes. If procedure is not followed
carefully, damage to the SLICE-QTC or
devices connected to it may occur.
Potential for electrical shock hazard.
Specifications
Performance
3)
Parameter Value
Channels 4
Loop Filter
PID, adjustable corners and
proportional Gain
Control Range -10 to +120°C
Compatible Transducer TEC or resistive heater
Compatible Sensor
NTC thermistor
4)
Temperature Stability
±0.2 mK over 10 min
5)
Precision ~1 mK
Control Capacity
40 W total
6)
20 W max for a single channel
Current Capacity
6 A per channel
7)
Compliance Voltage
≤18 V
8)
Input & Output
I/O Voltage Range ±10 V
Triggering TTL
Control Interface
Control
Front-panel touch screen, GUI, Serial
API
Connections Host control: USB Type B
Tab. 3: Specifications of SLICE-QTC
Extendable Legs
The SLICE-QTC has four extendable legs (figure 2). Extending the front legs allows easy viewing from
above (figure 1) and extending the rear legs (figure 3) allows easy viewing from below.
