A.1 VES-A00-P Detector Commissioning Configuration
To record the detector's configuration you can print it using Xtralis VSC. To print the configuration select the
detector on the Xtralis VSC tree view at left and choose the Print command on the File menu.
A.2 ASPIRE Data
Print the ASPIRE Installation Data Pack (IDP) in order to record the ASPIRE modeling results for the system.
A.3 Smoke Test
TableA-2: Smoke Test commissioning form
Test Results
Test Method
Type of Smoke
Test Date
A.4 Air Sampling Test Results
TableA-3: Air Sampling Test results commissioning form
Pipe 1 Pipe 2 Pipe 3 Pipe 4
Transport Time from
End Cap Hole
Test 1 Initial Response
Fire1 (Alarm)
Peak Smoke
Test 2 Initial Response
Fire1 (Alarm)
Peak Smoke
