VESDA-EVES-A00-P Product Guide
20 www.xtralis.com
A
B
Figure4-6: Tabs used to remove top and bottom cover
Legend
A Top cover retaining tabs
B Bottom cover retaining
tabs
4. Detach the tethers, Figure4-7 and Figure4-8. (You can leave the cables from the detector to the fascia
connected.)
Figure4-7: Detaching the tethers
